Rs60k series Sliding potentiometer

Product Number：RS60K11A9010

Number of Resistors Single Connection
Installation Direction Vertical
Travel 60mm
Type Standard type
Operations Shape 9-T (T-Bar)
Operating length 8.2mm
Total resistance 10 K
Resistance Law 15A
Use temperature range -10 to +60 C
Permissible difference of total resistance value (+20%)
Maximum operating voltage 350V AC, 20V DC
Rated power 0.25W
Insulation resistance 100Mmin. 250V DC
Voltage resistant 250V AC for 1 minute
Mechanical Performance - Motion Force 0.3 (+0.3, -0.2)N
Stop Strength 100N
Push-pull strength of operating unit 100N
Transverse vibration of operating unit (both sides) 1.312mm
The eccentricity of the operating part (one side) is 0.5mm max.
Durability - Operating life 100,000 cycles
Minimum Order Unit (pcs.) Japan 50
Export 100
Welding Conditions
Reference examples of manual welding methods
Pyramid head temperature 350 C max.
Welding time 3S max.
Number of welds 1 time
