| Place of Origin: | Shenzhen,China |
|---|---|
| Productivity: | 200pcs/day |
| Payment Type: | T/T,Paypal,Money Gram,Western Union |
| Incoterm: | EXW |
| HS Code: | 9032100000 |
| Transportation: | Ocean,Air |
| Port: | Shenzhen |
Product Description
Product Description
About HW-9137A+ PID temperature control system development:
- One stage output only for heating.
- High accuracy controling (0.1C/F degrees)
- Replacable waterproof stainless sensor probe.
- NEMA 4X/IP65 gasket front panel.
- Dual MCU IC chip, safety controlling and fast computing.
- Goodsky relay with UL/CE certification, constantly click more than 100,000 times lifetime.
- Optional input: AC110V/220V.
- Celsius and Fahrenheit display unit switchable.
- High & low temperature alarm system.
- Timing off function.
- Limited temperature pre-setting for protection.
- Power off data save protection.
What does the HW-9137A+ can do for you?
The control range for 9137A+ is -30℃ ~300 ℃ / -22℉~572 ℉, most of the user choosed it for high temperature controlling.
Its specially developed for high accuracy temperature controling application such as home brewing,incubation.
9137A+ series only has a single way output, and it only works with heater.
Fast to learn the difference between each temperature controller.
|
Model |
Probe Measurement Range |
Input (Optional) |
Accuracy |
Load (Intermediate relay extend available ) |
Controlling Model |
Delay Working |
C/F Display Unit Switch |
Adjusting Value |
| 9137A |
(-50℃ ~110 ℃ / -58℉~230℉) |
AC 110V,220V |
± 0.1 ℃ / ℉ |
5Amp |
Singel way output,only heating mode, PID control system, high accuracy temperature controlling,apply to incubator, homebrewing which need a high precision temperature. |
Yes |
Yes |
0.1 / 0.5 |
| 9137A+ |
(-30℃ ~300 ℃ / -22℉~572 ℉) |
AC 110V,220V |
± 0.1 ℃ / ℉ |
5Amp |
Singel way output,only heating mode, PID control system, high accuracy temperature controlling,apply to incubator, homebrewing which need a high precision temperature. |
Yes |
Yes |
0.1 / 0.5 |
| 1803C |
(-50℃ ~110 ℃ / -58℉~230℉) |
AC 110V,220V |
± 0.1 ℃ / ℉ |
5Amp |
Singel way output with plug socket,only heating mode, PID control system, high accuracy temperature controlling,apply to incubator, homebrewing which need a high precision temperature. |
Yes |
Yes |
0.1 / 0.5 |
