Best seller Laptop Charger Adapter for NEC

Laptop Power Supply 19V 6.3A comaptiable for NEC

Nec Computer Laptop Charger

Instructions for use of the Nec Adapter
Before use, you must read the product introduction and instructions, see the wiring marks, and confirm that the input voltage is consistent with the provided brand.
Second, when wiring, please cut off the input power supply. For the power supply with a larger power, the output end is composed of multiple tie terminals, and the inside of the terminal is the same, and the load should be evenly connected.
For high-power power supply, pay attention to whether the use space is enough to facilitate heat dissipation and extend the life of the power supply;

Replace Part Numbers:

CP163061-02, FMV-AC316 FPCAC36......

compatible with:

N-3000 N-3010 N-5000 N-5010 N3000 N3010 N5000 N5010 N04 N53 N58 N61 American Sunrex corp Geforce 4 8600 8200 2800 f10503-A PROSTAR 9870 SERIES 9870 982 5190 5100S 2100 2100P 3550 3100C 4283 4200 3593 3100P 3150 3100C 2293 2200s 2253 2200c 2273 2200t........

Nec Charger highlights:

1. High quality,high efficiency and stable of adapter

2. Built-in OVP OCP OTP and SCP

3. Full power ,No load power consumption 0.3w-0.5w

4. 100% full test from raw material to finished products

5. Output voltage,current, plug,dc size can be customized

Products specifications of Nec Laptop Charger:

Output :19v 6.32a 120w

DC Connector Size:5.5*2.5

Nominal Input Voltage:AC100-240V

Input Frequency:50/60Hz

Adapter size:16.6*6.5*3.9CM

Adapter Weight:670G

Line Regulation:2%

Load Regulation:5%

Ripple Noise:180 Mvp-p

Efficiency:>85%

Operating Temperature:0°C ~40°C

Operating Humidity:5%~95%RH

Storage Temperature:-20°C ~85°C

Storage Humidity:5%~95%RH

Warranty: 2 years(nec notebook adapter)

Certificates:CE, ROHS, REACH, FCC, ERP, CB, GS, TUV, UL, CUL, CCC,PSE

MOQ:100pcs

Package of nec laptop charger:

♦ Inner box size: 19*13*4.7 cm

♦ Inner box weight: 40G

♦ PCS/CTN: 50PCS

♦ Carton Size: 48.5 x 32 x 40cm

♦ Gross Weight: 17.36Kg (not include AC cable weight)
