23.8 Inch Capacitive touch Monitor

24 Inch P-cap monitor with EETI industrial touch program. Assembling method can be VESA wall mount, Open Frame or with folded metal stand. Interfaces is optional for VGA+DVI+HDMI+USB for touch or VGA+AV+BNC+HDMI+USB+TOUCH. 10 touch points. Shenzhen Bolinia Technology Co., Ltd. is an original factory for 7 inch to 32 inch lcd monitors and displays over 10 years. PCAP touch monitor from 8 inch to 24 inch. G+G touch program with VGA, AV, HDMI and USB interfaces. Other series we have are: CCTV monitor, HDMI monitor, resistive touch monitor, capacitive touch monitor, SDI monitor and so on.

• Display: 24 TFT High Definition capacitive touch monitor (16:9)
• Resolution: 1920*1080 pixels
• Brightness: 250 nits
• Contrast ratio: 1000:1
• Input voltages: 110 to 240V AC
• Output voltage: 12V DC
• Response time: 6 ms
• Viewing angle: 170°/160°
• Shell material: Aluminium frame with metal case
• Screen: tempered glass
•  Interfaces is optional for VGA+DVI+HDMI+USB for touch or VGA+AV+BNC+HDMI+USB+TOUCH


• Touch panel: G+G
• Surface hardness: 7H
• Transparency: >90%±5%
• Operating temperature: 0 to 50°C/20%-80%(non-condensing)
• Humidity temperature: 0-85% at 40°C (non-condensing)
• Storage temperature: -20 to 60°C/5-95%(non-condensing)
• Storage humidity: 5%~95%
• Connection Type: USB
• Response time: <10ms
• Operation voltage: 3.3V-3.6V DC
• Max supported points : 10
• System supported: Windows XP/7/8 Android, Linux

Other PCAP touch monitor sizes for options:

8 inch 800*600  1024*768
9.7 inch 1024*768
10.1 inch widescreen  1280*800
12.1 inch 800*600  1024*768
13.3 inch widescreen 1920*1080
15 inch 1024*768
15.6 inch widescreen  1366*768  1920*1080
17 inch 1280*1024
18.5 inch 1366*768
19 inch 1280*1024 or widescreen 1440*900
21.5 inch widescreen 1920*1080
23.8 inch widescreen 1920*1080

Company Show

Shenzhen Bolinia Technology Co., Ltd. is a manufacturer for 7-32 inch lcd monitors and displays. Own factory with assembling line in Shenzhen. Product ranges from plastic monitor, metal monitor, resistive touch monitor, capacitive touch monitor, open frame monitor, embedded monitor to SDI broadcasting monitor. Square monitor or wide screen monitors are available with different resolutions.

Single touch monitor with resistive 4 wire and 5 wire for options from 7 inch to 22 inch.
Multi-touch projected capacitive touch (PCAP Touch or PCT) monitor from 8 inch to 24 inch.
SDI monitor from 15 inch to 21.5 inch.

Products mainly used in ATM, POS, CCTV security, Information checking, Kiosk, BGA repairing station, microscopes and similar applications.

Our service

Sample service: 1~10 samples could be sent out within 2 days after the full payment;

Customized service: for the custom made LCD monitor, our design team could finish it at most one month with a very quick effective and flexible way;

After sale service: 24 hours on line service through the website is available; if you meet with the technical problems, our technicians will reply to you within 24 hours.

 FAQ

Q: Why choosing Bolinia?

A: 1. LCD monitor factory since 2004 with rich experience

     2. Industrial grade panel with durable PCB board

     3. Factory price

     4. Quality guaranty by QC team

     5. OEM/ODM supported

Q: How about the lead time?

A: That's depends on your order quantity and our production schedule. Normally, 2-5 working days for 19 inch cheap touch screen monitor order and 15-20 working days for bulk order after confirming of payment

Q: What payment term do you support?

A: T/T in advance, PAYPAL, Western Union and L/C(Only when amount is above 100,000USD)

Q: What's your warranty?

A: All of our products share 12 months warranty. On-line service and additional accessories supported
