Chinese Vertical VTC500 CNC Drilling Tapping Milling Machne Center

Features: 1.Drilling, Tapping Processing,also milling chambering etc function. 2. Fanuc or Mitsubish control system with servo motor and drive to realize 3 axes linkage. 3. Key parts like spindle, ball screw,linear guid way, spindle motor,X Y Z motor, bearing etc use famous brand parts. 4.Applicable for single work piece or batch processing of holes on top surface of small to medium box or holes on flat plate.     Specifications

Model		VTC500	VTC500H*	VTC600	VTC700	VTC700H*
Table Size		620*420mm	620*420	700*420mm	800*420	800*421
	Longitude(X)	500mm	200	600mm	300	300
Travel	Crossward(Y)	400mm	500	400mm	700	700
	Vertical (Z)	300mm	400	300mm	400	400
Distance between spindle and Table		200-500mm	300	200-500mm	300	300
Distance between spindle and Column		420mm	200-500	420mm	200-500	200-500
	Rotation Speed	10000rpm	420	10000rpm	420	420
Spindle	Taper	BT30	12000*/15000*	BT30	10000	12000*/15000*
	Motor	5.5kw	BT30	5.5kw	BT30	BT30
	Longitude(X)	48m/min	7.5	48m/min	5.5	7.5
Rapid Feed	Crossward(Y)	48m/min	48	48m/min	48	48
	Vertical (Z)	48m/min	48	48m/min	48	48
Cutting Feed		10m/min	48	10m/min	48	48
Positioning Accuracy		0.005mm/m	10	0.005mm/m	10	10
Min Enactment Move Unit		0.001mm	0.005	0.001mm	0.005	0.005
Dimension (L*W*H)		1650*2050*2200mm	0.001	1850*2050*2200mm	0.001	0.001
Net Weight		2700kg	1650*2050*2200	2800kg	1850*2050*2200	1850*2050*2200
Max Loaded of Table		200kg	2700	300kg	2900	2900

       Accessories: 1.Standard accessories

1) Japan FANUC 0i-MATE/αControl system

2) Japan FANUC Servo Motor

3) Japan FANUC Drive

4) Automatic Lubrication one set;

5) Coolant system

6) Pneumatic system

7) Movable control hand wheel one set

8)Full Cover

9)Working Light one set

10)Alarm light

11)Tool magazine

12)RS-232 Connection one set

13) Clamping kit one set

14)Vise one set

15) BT30 milling chuck and collect one set

16) Spindle

17)Tool and toolbox one set

  2.Optional accessories

Oil water seperation system

Oil coolant

Auto chip conveyor

NC rotary table

Cleaning gun

   Package Reference Picture     Processed Sample Reference Picture     After-sales Service:   * 1 year guarantee for whole machine, we offer FOC parts for quality problem within guarantee * 24 hours technical calling or e-mail service for any technical questions of our machine * We offer detailed User Manual for machine installation, operation, and also for Software   Factory Overview     Production workshop     Our development team      Professional R&D team, OEM ODM service    Certificate of honor There are 8 Intellectual property rights,5 the patent In 2008, Our own brand”JOINT” has been the top quality machine’s signal in domestic sales JOINT also has been recognized as”Guangdong Famous Brand”  In 2008, Milling machine was recognized as” TOP 10 Famous Brand of Milling Machine “ in China ,In 2011,our company has been recognized as” national grade HI-Tech Enterprise”. The company set up a ISO9001:2000 quality guarantee system our product through “the country machine quality supervision and inspection center “certification testing
