Wall Mount Automatic IR Motion Sensor Light Switch (180 to 250V AC)

Wall Mount Automatic IR Motion Sensor Light Switch (180 to 250V AC)

Get Latest Price

Payment Type:: T/T, Western Union, PayPal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, Western Union, PayPal

Product Description

Specifications:

Model no.: TDL-9958J
Function description relay controls load
Operating voltage: 110V to 250V AC (50 to 60Hz)
Operating temp.: -20 to +50°C
Static power: Load power: 800W
Load capacity: suitable for all kinds of lights, appliances
Connecting style: input 220V AC, output 220V AC
Output mode: induction output
Light control range: 5 to 500lux ± 20% (adjustable)
Delay shutdown time: 16 to 350 secs. ± 30% (adjustable)
Induction mode: passive
Induction angle: 360°coning angle
Detecting distance: 5 to 7m
Installing method roof installation/ceiling installation
Dimension/color: 89 x 36 mm/porcelain

Range of application and function and features:

Automatic induction: when people enter into the range of induction, it will turn on, when people leave, it will turn off with delay
It can be applied to corridor, passageway, toilet, basement, warehouse, garage and more, which have the function of automatic lighting, and control
Photosensitive control: it adopting photoactive control, it doesn't turn on during daylight or in strong light environment
Automatic random delay: after it turns on,in the delay period,if there is presence of people, it keeps on working until people leave, than turn on with delay
Status indicator: efficient LED indicator, which is easy for installation and fault analysis
Temperature compensation: Tuodi specialized temperature compensation chip, which used to reducing the effect of temperature on detecting distance

Model no.: TDL-9958J

Function description relay controls load

Operating voltage: 110V to 250V AC (50 to 60Hz)

Operating temp.: -20 to +50°C

Static power: Load power: 800W

Load capacity: suitable for all kinds of lights, appliances

Connecting style: input 220V AC, output 220V AC

Output mode: induction output

Light control range: 5 to 500lux ± 20% (adjustable)

Delay shutdown time: 16 to 350 secs. ± 30% (adjustable)

Induction mode: passive

Induction angle: 360°coning angle

Detecting distance: 5 to 7m

Installing method roof installation/ceiling installation

Dimension/color: 89 x 36 mm/porcelain

Automatic induction: when people enter into the range of induction, it will turn on, when people leave, it will turn off with delay

It can be applied to corridor, passageway, toilet, basement, warehouse, garage and more, which have the function of automatic lighting, and control

Photosensitive control: it adopting photoactive control, it doesn't turn on during daylight or in strong light environment

Automatic random delay: after it turns on,in the delay period,if there is presence of people, it keeps on working until people leave, than turn on with delay

Status indicator: efficient LED indicator, which is easy for installation and fault analysis

Temperature compensation: Tuodi specialized temperature compensation chip, which used to reducing the effect of temperature on detecting distance
