High-definition 1,024 x 768P 9.7-inch LCD Monitor with HDMI/VGA/AN/BNC

High-definition 1,024 x 768P 9.7-inch LCD Monitor with HDMI/VGA/AN/BNC

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Main applications:

Industrial video microscope, industrial endoscope, flatness detector, dimensional detector, hot press, BGA rework station, laser engraving equipment, laser marking machine, rocker camera, CCTV monitor, PoS system and more

Features:

Screen display: 9.7-inch color LCD display (4:3)
Resolution: 1,024 x 768 pixels
Display area: 96.61*147.46mm
Contrast: 400:1
Brightness: 300cd/m²
Viewing angle: 150/150°
Power consumption: 110-240V input, 12V output
Storage temperature: -20-70°C
Operating temperature: 0-60°C
Humidity temperature: 10-95% RH at 40°C (non-condensing)
Panel type: LCD
Backlight: LED
Screen color: 16.7M
Response time: 8ms

Packing:

Dimensions: 24.4×17.2×3.7cm
Box packaging dimensions: 36.5×22.5×7.5cm

Interfaces:

HDMI input x 1
VGA (PC) input x 1
AV input x 1
BNC input x 1
TV (optional)

Installation:

Custom stand
Standard VESA wall mount (optional)
Rugged metal frame, anti-static, anti-magnetic field, strong anti-interference

Services:

Sample service: 1-10 samples could be sent out within 2 days after the full payment
Customized service: for the custom made LCD monitor, our design team could finishing it at most one month with a very quick effective and flexible way
After sale service: 24 hours on line service through the website is available
If you meet with the technical problems, our technicians will reply to you within 24 hours

Industrial video microscope, industrial endoscope, flatness detector, dimensional detector, hot press, BGA rework station, laser engraving equipment, laser marking machine, rocker camera, CCTV monitor, PoS system and more

Screen display: 9.7-inch color LCD display (4:3)

Resolution: 1,024 x 768 pixels

Display area: 96.61*147.46mm

Contrast: 400:1

Brightness: 300cd/m²

Viewing angle: 150/150°

Power consumption: 110-240V input, 12V output

Storage temperature: -20-70°C

Operating temperature: 0-60°C

Humidity temperature: 10-95% RH at 40°C (non-condensing)

Panel type: LCD

Backlight: LED

Screen color: 16.7M

Response time: 8ms

Dimensions: 24.4×17.2×3.7cm

Box packaging dimensions: 36.5×22.5×7.5cm

HDMI input x 1

VGA (PC) input x 1

AV input x 1

BNC input x 1

TV (optional)

Custom stand

Standard VESA wall mount (optional)

Rugged metal frame, anti-static, anti-magnetic field, strong anti-interference

Sample service: 1-10 samples could be sent out within 2 days after the full payment

Customized service: for the custom made LCD monitor, our design team could finishing it at most one month with a very quick effective and flexible way

After sale service: 24 hours on line service through the website is available

If you meet with the technical problems, our technicians will reply to you within 24 hours
