Dreambox 800 HD Se

 Product Description

DM800se with 2.10SIM&BCM 4505 tuner DVB800se white colour withe Dreambox 800 HD se, DM 800HD se, Dreambox 800se decoder, DM 800HD se satellite receiver, DM 800se TV receiver, DM 800 HD se Set Top Box. DM800se DM 800HD se White&Black colour available Dreambox 800 HD se
1. 400 MHz MIPS Processor
2. Enigma2. Linux Operating System
3. Colored OLED - Display MPEG-2 / H. 264 Hardware decoding
4. Big cooling fan no noisy at all

DVB receiver 800 HD se
Powerful receiver for digital TV and Radio programs.
Main features are a 400 MHz processor the DVB receiver 800 HD se supports the Linux TV API
Have a look to HighDefinition TV on your DVB receiver
Upgrade to SIM2.10

1. 400 MHz MIPS Processor (DM800 only have 300MHz. )
2. Colored OLED Display (DM500HD do not have)
3. HDMI connector. (Not DVI connector)
4. Plug & Play Slot for an internal2, 5" SATA hard diskor eSATA.
5. 10/100MBit compatible Ethernet Interface.
6. Plug & Play Tuner(Can Change the Tuner into DVB-C, DVB-T. )
7. 2 x USB 2.0 (DM500HD only have one)

Technical Features
400 MHz MIPS Processor
Enigma 2, Linux Operating System
Colored OLED - Display
MPEG-2 / H. 264 Hardware decoding
Tuner: DVB-S, optional: DVB-C, DVB-T
Tuner Module, Plug&Play
2 x Smartcard-Reader
Mini USB for Service and software update
10/100Mbit Ethernet Interface
1 x Scart (RGB, FBAS or S-Video)
HDMI
2 x USB 2.0 (e. G keyboard)
Analog modem
S/PDIF Interface for digital bit stream out (AC-3)
64 MByte Flash, 256 MByte RAM
SATA- for internal HDD 2, 5"
Unlimited channel lists for TV/Radio
Channel-change time < 1 second
Automatic service scan
Directly bouquet-lists
EPG (electronic program guide)
Multiple LNB-Switching control (supports DiSEqC)
OSD in many languages and skin-support
Videotext Decoder
Extern 12V power supply
DVB receiver 800 HD se technical data
DBS-Tuner mit DVB-S2:
Frequency Range 950...2150 MHz
Demodulation DVB-S (QPSK); DVB-S2 (8PSK, QPSK)
Symbol rate DVB-S: 2...45 Mbaud/s, SCPC/ MCPC
DVB-S2: 10 -31 Mbaud/s (8PSK), 10 -30 Mbaud/s (QPSK)
Video decoder:
Video Compression MPEG-2 and MPEG-1 compatible, H. 264
Video Formats 4: 3 / 16: 9
Letterbox for 4: 3 TV-Device
Audio decoder:
Audiokompression MPEG-1 & MPEG-2 Layer I and II, MP3
Audio Mode Dual (main/sub), Stereo
Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz
Output analog:
Output Level L/R 0, 5 Vss on 600 Ohm
THD > 60 dB (1 kHz)
Crosstalk < -65 dB
Output digital:
Output Level 0, 5 Vss on 75 Ohm
Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz
S/PDIF-Output optical, Toslink
Ausgang Video:
Ausgangspegel FBAS 1 Vss +/- 0.3 dB an 75 Ohm
Video parameter:
Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm
Teletext filter in conformity with ETS 300 472 Standard
TV-Scart:
Output: FBAS, RGB, S-Video
Mini USB service connector:
Function: Update of Firmware
Ethernet:
10/100 MBit compatible interface
Function: Update of Firmware
Analoge modem:
Analoge modem for Internet connection
SATA Interface:
For internal 2, 5" HDD
USB
2 x USB 2.0
LNB power and polarisation per tuner:
LNB Current 500mA max.; Short-circuit-protected
LNB Voltage vertical < 14V no load, > 11, 5V at 400mA
LNB Voltage horizontal < 20V no load, > 17, 3V at 400mA
Count of active satellite position:
DiSEqC 1.0/1.1/1.2 and USALS (Rotor Control)
Power consumption:
< 15W at 12V
External PSU
Input:
110-240V AC / 50-60Hz / 0, 6A
Output:
12V = / 3, 0A
Physical specification:
Ambient Temperature +15° C...+35° C
Humidity < 80%
Size (W x D x H): 225 mm x 145 mm x 52 mm
Weight: 940 g without HDD
