14.8V 4400mAh LiFePO4 18650 Rechargeable Battery

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Transportation:	Ocean,Air,Express

Product Description

Basic Info.

Installation

Packaged

Rechargeable

Chargeable

Transport Package

Carton Box

Trademark

Origin

China

Production Capacity

5, 000, 000 PCS/Year

14.8V 4400mAh Lifepo4 18650 rechargeable battery

Product Specification

Item	Criteria	Remarks
Weight	500g
Typical capacity	4400mAh	0.5C charge and 0.5C discharge for cut-off voltage
Minimum capacity	4400mAh	0.5C charge and 0.5C discharge for cut-off voltage
Nominal voltage	14.8V
Internal impedance	cell:≤60m	AC 1KHz after standard charge
Internal impedance	Battery: ≤200m	AC 1KHz after standard charge
Chargevoltage	16.8V
Standard charge current	2200mA
Max. charge current	2200mA
Max. discharge current	2200mA
Discharge cut-off voltage	11V
Operating temperature	0~+45ºC	Charging
Operating temperature	-20~+60ºC	discharging
Storage temperature	within 1 month:-5 ºC~+45ºC	Relative humidity: 65±20%RH
	within 3 month:-5 ºC~+35ºC
	within 6 month: 0 ºC~+35ºC
Semi-manufactured cell	EA 18650-2200MAH	8PCS
PCM		1PCS

PCM Parameter

Item	Criteria
Over-charge protection voltage	4.25
Over-discharge protection voltage	2.75
Over current detection current	5A-8A
Initial Impedance	≤60m
Operation Station Current	8.0μA Type 10μA Max
Temperature control switch	70ºC
