5.1-channel audio decoder
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 2 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Supply Ability: | 5000 pcs/month |
2, support analog stereo audio signal (R / L) decoding, output 5.1 or 2.1 channel analog audio signal
3, one input for digital OPTICAL (fiber) audio signal, one for digital COAXIAL (coaxial) audio signal input, and another for analog input AUX (Stereo). More complete to multi-channel digital audio and analog audio input
4, multi-channel signal input, one-button switch, convenient
5, automatically detects the signal input channel, and switch to the signal input channel, when there is no signal input, it will output mute function
6, 6-RCA (RCA) output, output analog 5.1 or 2.1 channel, one-button switch, power off memory save feature
7, 24-bit audio DSP, 96KHZ/24bit ADC and DAC digital processing chip
8, the noise ratio: 120db
9.degree of separation: 80db (1KHZ)
10, frequency response: 20HZ-20KHZ ± 0.5dB
11, analog output level: 2.2V
12, size: 105 * 75 * 25mm
1, input interface: OPTICAL (fiber), COAXIAL (coaxial), AUX (analog stereo)
2, the power supply and switch: DC/9V/1A (DC 9 V 1 A) External power supply. 5.1/2.1 switch SW input channel switch (cycle switching)
3, Indicator: when power on, power indicator light on. When digital signal inputting, the indicator corresponding to the D1, D2 . When Analog stereo signal inputting, only the power indicator light on.
4, the output interface features: subwoofer (SW), center (CE), rear right (SR), rear left (SL), front right (FR), front left (FL)
5: output interfaces are 6 Lotus head interface, providing a more stable and reliable signal output
Product advantages
1, input and output interfaces: Input optical fiber, coaxial and analog 3.5mm audio. Output of the SW, the CE, the SR, SL, FR, FL
2, high-speed audio decoder chip can decode the DTS / Dolby AC-3 digital audio source
3, a wide range of applications: computer PC, notebook, the PS3, XBOX360, high-definition player, HD set-top boxes, DM500/DM800, Blue - ray DVD, HD-CD, KTV audio
4, refined products, compact and convenient, plug and play, strong mobility.
Product Annex
Accessories Quantity Remarks
SX-512 audio decoder 1 black
power adapter DC 9V 1 1
Fiber-optic line 1 1M
Manual 1 Chinese / EN
