850nm IR/Infrared line laser module
- Payment Type:
- L/C, Paypal
- Min. Order:
- 5 Bag/Bags
- Min. Order:
- 5 Bag/Bags
- Delivery Time:
- 14 Days
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Supply Ability: | 10000 pcs |
| Payment Type: | L/C,Paypal |
| Port: | Shenzhen |
850nm IR/Infrared line laser module
Wavelength:850nm
Output power:1mW,5mW,10mW,20mW,30mW
Beam Divergence:0.1mrad ~ 0.6mrad
Line thickness: Less then 2mm at 5m
Laser line accuracy:<30"(at 5m)
Fan angle:10°~120°
Operating Voltage:DC3-5V
infrared laser module Specifications:
Laser Module Wavelength:850nm
Output power:1mW,5mW,10mW,20mW,30mW
Beam Divergence:0.1mrad ~ 0.6mrad
Line thickness: Less then 2mm at 5m
Laser line accuracy:<30"(at 5m)
Fan angle:10°~120°
Operating Voltage:DC3-5V
Operating Temperature:-10℃~70℃
Storage Temperature:-30℃~80℃
Dimensions:16x60mm
MTTF: 8000 hours
IR / Infrared Laser Module Characteristics:
High-quality laser diode,optical glass lens, driver circuit and housing
Better line quality
High reliability, high stability, long life,low price
Applications:
Machine vision
Industrial inspection
Industrial marking devices
3D contour mapping
Positioning & visualization
Biomedical
High-end alignment
Laser targeting devices and so on..
