Renewable Energy Cable pv1 f

Introducing the PV1-F, our dependable solar cable that's tailored for your solar energy setups. It's made with an eye for both performance and reliability, and it's meant to bring efficiency and long-term use to renewable energy systems.
The PV1-F is put together with care, resulting in a robust build that offers good electrical conductivity and resistance to the elements. It's 6mm across, which strikes a balance between being easy to handle and install, and maintaining solid electrical qualities.
We make these cables to match top industry standards, including the strict requirements of the IEC 62930 certification, to ensure that they're safe and work well with a variety of solar equipment. So whether it's a small home setup or a big solar farm, the PV1-F solar cable is built for consistent connections and sustainable power flow.

Key points about the PV1-F:
Reliable Solar Cable: It's made specifically for use in solar energy roles.
6mm Flexible Design: This makes it straightforward to work with and install.
Strong Conductivity and Environment-Resistant: It's designed to perform well electrically and stand up to weather and more.
Certified to Industry Standards: It meets the IEC 62930 standard, indicating it's recognized for its safety and compatibility.
Versatile Use: Suitable for home, business, or industrial solar panel systems.
Our PV1-F solar cables are here to offer you a steady and effective way to connect your solar system. They're built with the goal of getting the most from solar power, providing a dependable solution ready to last. Try the PV1-F and give your solar projects a solid foundation.

Renewable Energy Cable pv1 f

Standards:  IEC 62930,  PPP 59074A,  EN50618：2014

Conductor: Class 5 Tinned Copper according IEC60228
Insulation: Halogen Free, cross-linked, flame retardant compound

Cores: Single core, Flat 2 cores
Sheath: Halogen Free, cross-linked, flame retardant compound
Nominal Voltage:  AC 1000/1000V,  DC 1500V  DC 18000V
Test Voltage: 6500V, 50Hz, 5Min
Temperature Rating: -40°C to 90°C ,More than 25 Years
Flame retardant according to IEC/EN 60332-1-2
Low smoke Halogen free according to IEC/EN 60754-1/2

UV Resistant according to HD 605 S2   EN60811-501
