PVC insulated RVV H05VV-F 5 Core Flexible Cable
- Min. Order:
- 5000 Meter
- Min. Order:
- 5000 Meter
- Transportation:
- Ocean, Land, Air
- Port:
- Shenzhen, Guangzhou, Shanghai
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 70 kilometer/ day |
| Supply Ability: | 70 kilometer/ day |
| Payment Type: | L/C,T/T,D/P,D/A |
| Incoterm: | FOB,CFR,CIF,EXW,FAS,FCA |
| Certificate: | CE, ISO |
| HS Code: | 854449 |
| Transportation: | Ocean,Land,Air |
| Port: | Shenzhen,Guangzhou,Shanghai |
CE Approved H05VV-F H05VVH2-F PVC Flexible Control Cable 300/500V
Conductor:
Class 5 flexible plain copper conductors
Insulation:
PVC (Polyvinyl Chloride)
Sheath:
PVC (Polyvinyl Chloride)
Sheath Colour:
White/Black
Voltage Rating:
300/500V,450/750V
Temperature Rating:
-5°C to +70°C
Technical data:
Standard: IEC60 227
Nominal voltage: 300 / 500 V,450/750V
Test voltage: 2000 V
Inflammability test: IEC 332-1-2
Max. permmisible temperature - fixed insulation: - 40 °C do + 70 °C
Max. permmisible temperature - flexing: -5 °C do +70 °C
Specific insulation resistance, 70 °C 108 Ωm
Minimum bending radius: 6 x ∅
Description:H05VV-F H05vvh2-f pvc Insullation cable composed of fine wire conductor, class 5,insulated with a layer of PVC compound .
It has two or more cores, bunch stranded and PVC sheathed .widely used designed for a wide range of industrial process automation applications,
including signal transmission, measurement, control and regulation.--FNYLHY cable , FNYMHY cable ,CY cable, SY cable, YY cable,
and LiYCY & LiYY cables
Why choose us-BDK Cable ?
1. We engaged in oversea market from 2008, supply oversea partners around 60 countries.
based on high quality, the cables had passed SAA certified, CE certified, CB certified,CCC and RoHS, etc; third party testing. We are well experience in producing the cables as per IEC, AS/NZS, BS,VDE, SABS, etc and clients’ request. We guarantee 100％ quality, on-time delivery, and 5-star after-sales services.
2. A large factory, annual turnover reach USD 0.3 Billion,bulk purchasing, standardized production, price competitive, quality assured, We have a great of advantage in types of LV power cables manufacturing and armored cable .
3. A leading, reliable Electrical Wires & Electrical Cables manufacture, we value your each inquiry, order, fulfill our each promise.
4. We have a great variety of wires and cables , IEC standards Flexible cable ,XLPE/PVC insulated Copper wire , House wiring , armoured power cable ,etc.. and AS/NZS standards Flat TPS Cable , Orange Circular Cable ,Building wire and so on…
