SM27W1 Wireless Remote Speaker Microphone
  • SM27W1 Wireless Remote Speaker Microphone
SM27W1 Wireless Remote Speaker Microphone

SM27W1 Wireless Remote Speaker Microphone

  • $1.00
    ≥1 Bushel/Bushels
Min. Order:
1 Bushel/Bushels
Min. Order:
1 Bushel/Bushels
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Product Description
Product Description
It works with ADA-01 to form SM27W1-A1 kit for meeting police dispatch.

Specifications of Hytera SM27W1
Specs_Acc_Audio
Weight about 120g
Color black
PTT Key available
Emergency Key available
Microphone Sensitivity –42±3 dB @ 1 kHz 3.0 V 2.2 K, 0 dB = 1 V/Pa
Speaker Power 2 W (rated); 2.5 W (max.)
Speaker Impedance 4 Ω±15% @ 1 kHz
Speaker Frequency Response 83±4 dB @ 1 kHz 1 W/100 cm
Communication Protocol Bluetooth V4.0
BT Range 8–10 m
Certification CE, FCC, and IC
Battery Life ≥ 15 h (5/5/90)
Charging Time ≤ 3.5 h
IP Rating IP54
Operating Temperature –20℃ to 60℃
Storage Temperature –20℃ to 60℃

Hytera is a professional tetra radio manufacturers, we provide tetra terrestrial trunked radio, emergency response communications and etc. Want to learn more about Hytera products and solutions? Please tell us your business needs, our specialist will analyse your pain points and offer the right solution.
