UNIQSCAN Walk Through Metal Detector UB500 with LED Display

UNIQSCAN Walk Through Metal Detector UB500 with LED Display

WALK THROUGH METAL DETECTOR
MODEL:UB500/6 zones standard

Parameters

Power Supply:	AC85V-264V
Working temperature:	-20℃--+50℃
Working Frequency :	4KHZ—8KHZ
Standard External size:	2200mm(H)800mm(W)580mm(D)
Standard Internal size:	2010mm(H)700mm(W)500mm(D)
Package size for door panels:	2260650260mm *1ctn
Package size for control unit:	780390250 mm*1ctn
Gross weight:	70KG

Characteristic & Function

Ø Six mutual over-lapping detecting zones, Simultaneous alarm from multi- zones;

Ø Sensitivity adjustable: Each zone has 100 sensitivity level

Ø Sound & LED alarm: Both Side LED indicator ,easily show where the metal is.

Ø Automatically count passengers and alarm times

Ø Alarm strength indicator on control panel

Ø Password protection: only the authorized person can operate.

Ø Easy assembly: designed with only 2 pieces cables and 8 screws, simply-to-follow instruction.

Ø Harmless to human body:is harmless with heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.

Ø Using high density fireproof material

Ø Program Self-diagnostic when power on, no need initial or periodic calibration

Ø Modularization design:easy for maintenance and replacement.

Ø Sensitivity Test piece: One yuan Coin, omnidirectional detection

Ø 4-8 hours backup battery (Option)

UNIQSCAN Walk Through Metal Detector UB500 with LED Display

Application

Exhibition center, Electronic Factory, Bank, Prison, Government office, Hotel etc
