Extra transparency self adhesive switchable smart film
-
$58.001-49 Square Meter
-
$55.0050-99 Square Meter
-
$52.00≥100 Square Meter
- Transportation:
- Express, Air, Ocean, Land
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Shenzhen,China |
|---|---|
| Productivity: | 100000 Square Meters per Month |
| Supply Ability: | 999999 Square Meters per Month |
| Payment Type: | T/T,Paypal,Money Gram,Western Union,Others |
| Incoterm: | EXW,Express Delivery,FOB,CIF,DDU,DDP |
| Certificate: | CE,SGS,IS9001,ROHS |
| HS Code: | 9013809000 |
| Transportation: | Express,Air,Ocean,Land |
| Port: | Shenzhen |
Our Company
Yuguang STG is a high cost-effective rear projection screen when it is in the translucent state, with the added advantage of being
able to be powered on to make the glass transparent and reveal a display behind. When in translucent mode, Goodoing STG allows
light to travel through the glass, meanwhile,Intelligent Film the molecular-level scattering oflight makes animagetobeprojectedonto theglass frombehindwithhigh solution using a projector. In case of the glass is powered on and the projector is switched off, the
High Transparency Laminated Smart Film display behind the glass can be disclosed, making Goodoing STG ideal for shop windows, Switchable Electric Glass Decorative Film product launches and training rooms, etc.
Product Description
Yuguang Switchable Transparent Glass(STG) consists of float glass, EVA/PVB and Yuguang Transparent film(STF) that form a kind
of laminated glass. The scientific principles lie in the STF, PDLC Switchable Glass Film when it is powered off, the liquid crystal
molecules fall into a random state,that diffuse light passing through the sandwich structure and to provide instant privacy. When it
is powered on, PDLC Switchable Electrochromic Glass the voltage drive the liquid crystal molecules align along the direction perpendicularto the film,then visible light go through STF and turns transparent.
Product Parameters
Extra transparency self adhesive switchable smart film
|
Item |
Mode | Specification | |
| Optical Parameter | Visible Light Transmittance |
Power on |
>83% |
|
Power off |
>53% |
||
|
Parallel Light Tansmittance |
Power on |
75% |
|
|
Power off |
<2% |
||
|
Haze |
Power on |
<4% |
|
|
Power off |
>95% |
||
|
Viewangle |
Power on |
>150° |
|
|
Electrical Parameter |
Operating Voltage |
Power on |
AC48V-65V/ 50Hz |
|
Response Time |
Power off-on |
<200ms |
|
|
Power Dissipation |
Power off-on |
6-8 W/㎡ |
|
|
Size Parameter |
Thickness |
0.38mm |
|
|
Maximum Size |
6000mm*2000mm |
||
|
Operating Parameter |
Operating Temperature |
-30°C-50°C |
|
|
Storage Temperature |
-40°C-70°C |
||
|
Service Times |
Power on |
>12 years |
|
|
Switching Times |
|
>2 millions |
|
Application
Factory
FAQ
1. How does Smart Film work?
In “Off State” when no electrical power is applied on the smart film the light is absorbed or scattered and the
film looks dark gray or white. In “On State” the light is transmitted and the film looks transparent.And we can
provide the video of installation!
2. What is the product lead time?
Lead time for PDLC Film is 3-5 days,for smart glass is 8-15days after received payment.
3. What is the size of your roll?
For white color: 1.0m, 1.2m, 1.5m, 1.8m,2m width* 50m length,and length can custonized
For grey color: 1.2m, 1.5m width* 50m length,and length can custonized
4. What are your shipment terms?
We deliver it by air/express transportation.
Customer clear custom, release and deliver to final destination.
5. Is there a MOQ (Minimum of Quantity)?
MOQ is flexible, but special color based of 1 roll.
6. What is the expected life of your products?
Life expectancy is more than 15 years.
