Excellent quality surface Mount Assembly

How do you assemble a circuit board?

SMT&Through-Hole Assembly

1. Add solder paste: This is the initial stage of PCBA  assembly process. At this stage, solder paste is added to the Electronic Components pad wherever soldering is needed...
2. Place the Electronic Components: After adding the solder paste to the component pad, it is time to place the component. The PCB passes through a machine that transfers these Electronic Resistor and Capacitor,Electronic connectors....
3. Reflow oven: This step is used to permanently fix the components on the board. After placing the components on the board, the PCB passes through the reflow oven conveyor belt...
4. Wave soldering: In this step, the PCB is passed through the molten solder wave. This will establish electrical...
5. Cleaning: Up to this step, all welding processes have been completed. During the soldering process, a large amount of flux residue will form around the solder joints.
