PCB Circuits Electronic Components Parts

There are two main types of Electronic connectors: patch (SMT) connectors and plug-in (DIP) connectors. FPC connectors, board-to-board connectors, SIM card connectors, header and female connectors, HDMI connectors, Cable Connectors I/O Connectors,and even high-end WIFI coaxial connectors are produced.
1) According to the appearance: circular electrical connector, rectangular electrical connector. Circular electrical connectors are the most used in military equipment (aeronautics and aerospace). Rectangular electrical connectors are mostly used on buile-up printed board of electronic devices.
2) According to the structure:
According to the connection method: threaded connection, bayonet (quick) connection, card lock connection, push-pull connection, direct plug connection, etc.;
According to the terminal connection form of the contact body: crimping, welding, winding; screw (cap) fixing;PCBA Manufacturing,Turkey PCB Assembly.
Classified by environmental protection: environmentally resistant electrical connectors and ordinary electrical connectors
3) According to the purpose: sealed electrical connectors, high temperature electrical connectors, separated electrical connectors, filter electrical connectors, power electrical connectors.
Among them, the connectors used inside the mobile phone include BTB connectors and FPC connectors. These connectors need to be tested before they can be used. The high-current shrapnel micro-needle module is used as the connection module to conduct current and transmit signals. effect. In the BTB/FPC connector test, the high-current shrapnel micro-needle module can firstly improve the test efficiency, secondly, it has a long service life, and thirdly, it does not produce any marks on the connector during the test, and the yield rate of the female seat can reach %. Ninety-nine or more.
Pcbcoming is a professional company which can supply one -stop sevices including cheap custom pcb fabrication,mulit-wiring printed board,Rigid-Flex Board,PCB Assembly products.
