What is Rogers PCB material?

Rogers is a type of high-frequency board produced by Rogers. It is different from the conventional PCB board—epoxy resin. It has no glass fiber in the middle, and uses ceramics base copper-clad laminates as the high-frequency material (ceramics base copper-clad laminates). Rogers Rogers has superior dielectric constant and temperature stability, and its thermal expansion coefficient of dielectric constant is very consistent with that of copper foil, which can be used to improve the deficiencies of PTFE substrates; it is very suitable for high-speed design, as well as commercial microwave and radio frequency applications. Because of its low water absorption, it can be used as an ideal choice for high-humidity applications, providing customers in the High frequency board industry with the highest quality materials and related resources, and fundamentally controlling product quality.

Rogers Rogers series classification:
RO3000 series: Based on ceramic-filled PTFE circuit materials, the models are: RO3003, RO3006, RO3010, RO3035 high-frequency laminates.
Roger 4003 series: Roger 4003 printed board, Roger 4350 printed board.
RT6000 series: Based on ceramic-filled PTFE circuit materials, designed for electronic circuits and microwave circuits that require high dielectric constants. The models are: RT6006 dielectric constant 6.15, RT6010 dielectric constant 10.2.
TMM series: composite materials based on ceramics, hydrocarbons, and thermosetting polymers, models: TMM3, TMM4, TMM6, TMM10, TMM10i, TMM13i. and many more
In PCB proofing, Rogers/Rogers is a special kind of sheet material, with certain technical thresholds, difficult to operate, and high cost. The general PCB proofing factory finds it troublesome to make, or because of the small number of customers' orders, they don't want to do it or rarely do it.
