SFP-10G-ER 10g sfp transceiver module for SMF 1550-nm wavelength Compatible
-
USD2001-0 Piece/Pieces
-
USD250≥1 Piece/Pieces
- Payment Type:
- T/T, Western Union
- Incoterm:
- EXW
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Delivery Time:
- 3 Days
- Transportation:
- Land, Air, DHL
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | china |
|---|---|
| Productivity: | 2000/week |
| Supply Ability: | 500000 |
| Payment Type: | T/T,Western Union |
| Incoterm: | EXW |
| Certificate: | ROHS,CE,FCC |
| Transportation: | Land,Air,DHL |
SFP+-ER
10Gbps SFP+ ER Transceiver,40KM Reach
Features
1.Compliant with SFF-8413 and IEE802.3ae
2.Data rate selectable ≤4.25Gbps or 9.95Gbps to 10.3Gbps bit rates
3.Cooled EML transmitter and PIN receiver
4.link length up to 40km
5.Low Power Dissipation 1.5W Maximum
6.-5ºC to 70ºC Operating Case Temperature
7.Single 3.3V power supply
8.Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power
9.RoHS compliant and lead free
Applications
1.10GBASE-ER/EW (with/without FEC)
2.10G Fiber Channel (with/without FEC)
Description
SFP+ER Transceiver is designed for 10GBASE-ER/EW, and 8.5G/10G Fiber- Channel applications.
The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. 6COM SFP+ER Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
