Toyota tester3 (kkgtech002@hotmail.com)

Standalone operations
ALLSCANNER runs it's own operating system which allows it to be used as a standalone tool without a PC attached during operation. Imagine writing your own C/C++ application to perform an on-road test, then use 802.11A/B/G WiFi to wirelessly download a vehicle's data as soon as it re-enters the repair facility. Your program could access GPS compact flash card to capture location information about the test-drive, or use a cellular modem and download telemetry from live tests! For standalone applications, this provides the features of a PC host and a PassThru device all in one package.
* Note: This package does NOT provide software applications. This is responsibility of the buyer.
(Software Specification Vedix® is the latest diagnostic software platform of ALLScanner® to work with the hardware of VCX®.the characters be shown as below:
* Diagnostic software can be operated under WinCE and Windows, available installation for Laptop or PDA.
* Automotive Diagnostic language (VDL) exploitation platform based on XML by self-determination and high efficiency database management system, these will make it easily to explore the vehicles.
* Continuously update for diagnostic software remotely. )

Customers Applications
* J2534 Independent Repair Facility tool
* Diagnostics using 3rd party applications *
* In-vehicle pass-thru data logging
* Standalone data logging or monitoring
* Fleet or public transportation data acquisition
* OEM Engineering
* OEM calibration reprogramming
* End-of-Line testing
* Dealer Service Tools
* 3rd party integrated solutions
* Specialized Customers

Hardware VCX® interface
CPU                     16 digit Dual Cell specialize CPU
RAM                     64KB RAM
FLASH                   256KB FALSH
Diagnostic Port         24PIN, self-determination design
Wireless Port           802.11b/g WIFI wireless
LED                     4 LED indicator light,indicate power and status.
Power                   DC 9V-28V
Consumption             3W
Size                    156(L)x86(W)x35(H)mm
Working Temperature     -20 to +70degrees
StorageTemperature      -40 to 85degrees
