Non-Telecentric Lens

Canrill Optics is a professional lens manufacturer. We provide Telecentric Lens, Telecentric Illuminator, lithography lens, Non-Telecentric Lens, lens optical, machine vision illuminator and so on. Want to know more? Please contact us.

As a professional optical lens manufacturer in China, Canrill also produces high-quality non-telecentric lens with consistently high-quality.

New series

WD range from 49mm to 1405mm, magnification from 0.1X to 1X

Smaller size for installation in small space

Support to 2/3' C mounting industrial lens

Specification Of Non-Telecentric Lens
Model Lens Grade WD (MM) Magnification (X) Object FOV (MM) Image FOV (MM) DOF (MM) Aperature Resolution (um) Preview (pdf)
XF-MH1X379 MH 379 1 11 11 1 F9.5 6.3
XF-MH1X288 MH 288 1 11 11 1 F9.5 6.3
XF-MH1X218 MH 218 1 11 11 0.91 F9 5.9
XF-MH1X184 MH 1 184 11 11 0.92 F9 5.9
XF-MH1X152 MH 152 1 11 11 0.85 F8.5 5.6
XF-MH1X124 MH 124 1 11 11 0.85 F8.5 5.6
XF-MH1X99 MH 99 1 11 11 0.85 F8.5 5.6
XF-MH1X81 MH 81 1 11 11 0.87 F8.5 5.6
XF-MH1X68 MH 68 1 11 11 0.85 F8.5 5.6
XF-MH09X401 MH 401 0.9 12.2 11 1.2 F9 6.6
XF-MH09X306 MH 306 0.9 12.2 11 1.1 F9 6.6
XF-MH09X233 MH 233 0.9 12.2 11 1.1 F8.5 6.2
XF-MH09X197 MH 197 0.9 12.2 11 1.1 F8.5 6.2
XF-MH09X163 MH 163 0.9 12.2 11 1 F8 5.9
XF-MH09X133 MH 133 0.9 12.2 11 1 F8 5.9
XF-MH09X106 MH 106 0.9 12.2 11 0.98 F8 5.9
XF-MH09X86 MH 86 0.9 12.2 11 1 F8 5.9
XF-MH09X72 MH 72 0.9 12.2 11 1.1 F8.5 6.2
XF-MH08X429 MH 429 0.8 13.8 11 1.4 F8.5 7
XF-MH08X329 MH 329 0.8 13.8 11 1.3 F8.5 7
XF-MH08X251 MH 251 0.8 13.8 11 1.3 F8 6.6
XF-MH08X213 MH 213 0.8 13.8 11 1.3 F8 6.6
XF-MH08X177 MH 177 0.8 13.8 11 1.2 F7.5 6.2
XF-MH08X143 MH 143 0.8 13.8 11 1.2 F7.5 6.2
XF-MH08X114 MH 114 0.8 13.8 11 1.2 F7.5 6.2
XF-MH08X93 MH 93 0.8 13.8 11 1.2 F7.5 6.2
XF-MH08X78 MH 78 0.8 13.8 11 1.2 F7.5 6.2
XF-MH07X465 MH 465 0.7 15.7 11 1.8 F8 7.5
XF-MH07X358 MH 358 0.7 15.7 11 1.6 F8 7.5
XF-MH07X275 MH 275 0.7 15.7 11 1.5 F7.5 7.1
XF-MH07X234 MH 234 0.7 15.7 11 1.5 F7.5 7.1
XF-MH07X194 MH 194 0.7 15.7 11 1.5 F7.5 7.1
XF-MH07X157 MH 157 0.7 15.7 11 1.4 F7 6.6
XF-MH07X125 MH 125 0.7 15.7 11 1.4 F7 6.6
XF-MH07X102 MH 102 0.7 15.7 11 1.5 F7 6.6
XF-MH07X86 MH 86 0.7 15.7 11 1.4 F7 6.6
XF-MH06X513 MH 513 0.6 18.3 11 2.6 F8.5 9.4
XF-MH06X396 MH 396 0.6 18.3 11 2.4 F8.5 9.4
XF-MH06X306 MH 306 0.6 18.3 11 2.3 F8 8.8
XF-MH06X261 MH 261 0.6 18.3 11 2.3 F8 8.8
XF-MH06X218 MH 218 0.6 18.3 11 2.1 F7.5 8.3
XF-MH06X175 MH 175 0.6 18.3 11 2.1 F7.5 8.3
XF-MH06X140 MH 140 0.6 18.3 11 1.9 F7 7.7
XF-MH06X114 MH 114 MH 18.3 11 2.2 F7.5 8.3
XF-MH06X96 MH 96 0.6 18.3 11 2 F7 7.7
XF-MH06X60 MH 60 0.6 18.3 11 2.1 F7 7.7
XF-MH05X580 MH 580 0.5 22 11 3.5 F8 10.6
XF-MH05X450 MH 450 0.5 22 11 3.2 F8 10.6
XF-MH05X350 MH 350 0.5 22 11 3 F7.5 9.9
XF-MH05X300 MH 300 0.5 22 11 3.1 F7.5 9.9
XF-MH05X250 MH 250 0.5 22 11 2.8 F7 9.2
XF-MH05X200 MH 200 0.5 22 11 2.8 F7 9.2
XF-MH05X160 MH 160 0.5 22 11 2.6 F6.5 8.6
XF-MH05X130 MH 130 0.5 22 11 2.9 F7 9.2
XF-MH05X110 MH 110 0.5 22 11 2.6 F6.5 8.6
XF-MH05X69 MH 69 0.5 22 11 2.8 F6.5 8.6
XF-MH04X681 MH 681 0.4 27.5 11 5 F7.5 12.4
XF-MH04X531 MH 531 0.4 27.5 11 4.7 F7.5 12.4
XF-MH04X416 MH 416 0.4 27.5 11 4.4 F7 11.6
XF-MH04X358 MH 358 0.4 27.5 11 4.5 F7 11.6
XF-MH04X299 MH 299 0.4 27.5 11 4.1 F6.5 10.7
XF-MH04X238 MH 238 0.5 27.5 11 4.1 F6.5 10.7
XF-MH04X190 MH 190 0.4 27.5 11 3.7 F6 9.9
XF-MH04X155 MH 155 0.4 27.5 11 4.1 F6.5 10.7
XF-MH04X131 MH 131 0.4 27.5 11 4.4 F7 11.5
XF-MH04X82 MH 82 0.4 27.5 11 4.1 F6 9.9
XF-MH04X49 MH 49 0.4 27.5 11 4.1 F6 9.9
XF-MH03X846 MH 846 0.3 36.7 11 9.5 F8 17.5
XF-MH03X664 MH 664 0.3 36.7 11 8.9 F8 17.5
XF-MH03X526 MH 536 0.3 36.7 11 7.2 F6.5 14.3
XF-MH03X454 N
XF-MH03X380 MH 380 0.3 36.7 11 7.9 F7 15.4
XF-MH03X301 MH 301 0.3 36.7 11 7.9 F7 15.4
XF-MH03X240 MH 230 0.3 36.7 11 7.7 F7 15.4
XF-MH03X195 MH 195 0.3 36.7 11 6.6 F6 13.2
XF-MH03X166 MH 166 0.3 36.7 11 7.2 F6.5 14.3
XF-MH03X105 MH 105 0.3 36.7 11 7.2 F6 13.2
XF-MH03X65 MH 65 0.3 36.7 11 7.3 F6 13.2
XF-MH02X1184 MH 1184 0.2 55 11 19.9 F7.5 24.6
XF-MH02X932 MH 932 0.2 55 11 18.6 F7.5 24.6
XF-MH02X746 MH 746 0.2 55 11 19.1 F7.5 24.8
XF-MH02X644 MH 644 0.2 55 11 19.2 F7.5 24.6
XF-MH02X541 MH 541 0.2 55 11 16.2 F6.5 21.3
XF-MH02X425 MH 425 0.2 55 11 16.2 F6.5 21.3
XF-MH02X341 MH 341 0.2 55 11 15.8 F6.5 21.3
XF-MH02X276 MH 276 0.2 55 11 17.6 F7 23
XF-MH02X236 MH 236 0.2 55 11 17.6 F7 23
XF-MH02X149 MH 149 0.2 55 11 14.6 F5.5 18.2
XF-MH02X96 MH 96 0.2 55 11 16.3 F6 19.8
XF-MH01X1405 MH 1405 0.1 110 11 70.6 F7 46.2
XF-MH01X1213 MH 1213 0.1 110 11 70.9 F7 45.7
XF-MH01X1023 MH 1023 0.1 110 11 59.1 F6 39.2
XF-MH01X799 MH 799 0.1 110 11 58.5 F6 39.2
XF-MH01X647 MH 647 0.1 110 11 58.4 F6 39.6
XF-MH01X518 MH 518 0.1 110 11 63.2 F6.5 42.5
XF-MH01X445 MH 445 0.1 110 11 63.4 F6.5 42.5
XF-MH01X280 MH 280 0.1 110 11 62.2 F6 39.2
XF-MH01X190 MH 190 0.1 110 11 64.3 F6 39.2
