Micro-Heated Molecular sieve air dryer
-
$1840.001-19 Piece/Pieces
-
$1748.00≥20 Piece/Pieces
- Transportation:
- Ocean, Land, Express, Air
- Port:
- SHENZHEN, GUANGZHOU, NINGBO
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | CHINA |
|---|---|
| Productivity: | 500pcs per day |
| Supply Ability: | 100PCS PER DAY |
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CFR,CIF,EXW |
| Certificate: | CE |
| HS Code: | 8419399090 |
| Transportation: | Ocean,Land,Express,Air |
| Port: | SHENZHEN,GUANGZHOU,NINGBO |
Pressure swing adsorption (PSA) is a new type of gas separation technology(YUKA desiccant compressed air dryer).
Taking adsorbent molecular sieve as an example, the principle is to use molecular sieve to "adsorb" different gas molecules to separate gas mixtures. It uses air as raw material, adopts high-efficiency, high-selectivity solid adsorbent to selectively adsorb nitrogen and oxygen, and realizes the separation of nitrogen and oxygen in the air.The separation effect of carbon molecular sieve on nitrogen and oxygen is mainly based on the different diffusion rates of these two gases on the surface of carbon molecular sieve. The smaller the diameter of the gas (oxygen), the faster it diffuses, and the more it enters the solid phase of the molecular sieve. In this way, nitrogen-rich components can be obtained in the gas phase.
After a period of time, the adsorption of oxygen by the molecular sieve reaches equilibrium. According to the different characteristics of carbon molecular sieve adsorbing gas at different pressures, the pressure is reduced to release carbon molecular sieve to adsorb oxygen. This process is called regeneration. The pressure swing adsorption method initially uses two towers in parallel, alternately performing pressure adsorption and decompression regeneration to obtain a continuous oxygen flow;
The desiccant for air dryer Technical Specification
| Model | Flow rate (m³/min) | Connection | Input Power (KW) | Power | N.W. (KG) | Dimension (MM) |
| HL-1WR | 1.2 | RC1" | 0.5 | 220V 50HZ | 135 | 670x360x1265 |
| HL-2WR | 2.4 | RC1" | 0.8 | 220V 50HZ | 170 | 780x360x1485 |
| HL-3WR | 3.2 | RC1" | 1 | 220V 50HZ | 240 | 850x400x1385 |
| HL-6WR | 6.5 | RC1-1/2" | 1.8 | 220V 50HZ | 285 | 1000x450x1700 |
| HL-8WR | 8.5 | RC2" | 2.4 | 220V 50HZ | 255 | 1100x500x2050 |
| HL-10WR | 11.5 | RC2" | 3 | 220V 50HZ | 526 | 1200x500x2030 |
| HL-13WR | 13.5 | RC2" | 3 | 220V 50HZ | 605 | 1300x500x2230 |
| HL-15WR | 17 | DN65 | 4.5 | 220V 50HZ | 712 | 1300x560x2360 |
| HL-20WR | 23 | DN80 | 6 | 220V 50HZ | 848 | 1400x560x2530 |
| HL-25WR | 27 | DN80 | 7.5 | 220V 50HZ | 1150 | 1650x820x2630 |
| HL-30WR | 34 | DN80 | 9 | 220V 50HZ | 1328 | 1750x900x2630 |
| HL-40WR | 45 | DN100 | 12 | 220V 50HZ | 1674 | 1850x750x2650 |
| HL-50WR | 55 | DN100 | 15 | 220V 50HZ | 2100 | 1950x850x2650 |
| HL-60WR | 65 | DN125 | 18 | 220V 50HZ | 2707 | 2200x1240x2705 |
| HL-80WR | 85 | DN150 | 24 | 220V 50HZ | 3573 | 2420x1260x2800 |
| HL-100WR | 110 | DN150 | 30 | 220V 50HZ | 4639 | 2500x1100x2750 |
| HL-120WR | 130 | DN150 | 36 | 220V 50HZ | 5100 | 2650x1200x2800 |
| HL-150WR | 155 | DN200 | 45 | 220V 50HZ | 5586 | 2800x1300x2900 |
The desiccant air dryer for compressor Feature& Advantage
Pressure dew point under rated conditions: -20 ° C ~ -40 ° C (molecular sieve up to: -70 ° C)
Intake oil content: 0.08ppm (0.1mg/m³)
Dust particle size of finished product: ≤ 60μm
Average re-flow rate: 15% treatment gas volume
Adsorption type: activated alumina (higher molecular sieve available)
Pressure drop: ≤ 0.021Mpa
Regeneration method: normal temperature regeneration
Working mode: two towers 4min or 10min automatic switching, continuous work
Control mode: cycle period 4~10min adjustable
Installation method: indoor, allowing no basic installation
Working Condition
Rated compressed air inlet temperature: 38 ° C, up to 45 ° C
Rated compressed air pressure: 0.7MPa, maximum 1.0MPa
