Hand-held integrated laser welding machine Product description

It’s an 1 to 2 laser welding machines with multi-function, two fiber can work simultaneously or time-sharing, weld type can switch between workbench and hand-held type.

Function characteristic

Use 500-1500 watt fiber laser, high efficiency of electro-optical conversion, the laser life is long up to 100,000 hours .

High efficiency of electro-optical conversion, free adjustment, low energy consumption, no consumables, small volume, long term use can save cost.

Large workbench.

Swing hand-held welding head: can weld complex workpiece, larger irregular shape workpiece, welding at any angle.

Welding surface smoothness, no need to polish, time-saving and labor-saving, elegant and firm.

It mainly apply to stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized plate, aluminum galvanized plate and other metal welding.

Applications

Used for all kinds of metal materials advertising characters welding, such as Stainless steel character, titanium gold character, seiko stainless steel character, Iron paint characters ect.

Model	UK-HJLX-SC500W	UK-HJLX-SC1000W	UK-HJLX-SC1500W
laser power	500w	1000w	1500w
Laser wavelength	1070±5nm	1070±5nm	1070±5nm
Operation mode	Continuous / modulation
Output welding joint type	Hand held swing head + welding head
Output power stability	<3%	<3%	<3%
Power regulation range	10~100%	10~100%	10~100%
Weld penetration	0.5~2.0mm	0.5~2.5mm	0.5~3.5mm
Cooling mode	Built in water cooling	Built in water cooling	Built in water cooling
Fiber line length	Holding 10 meters, fixed head 15 meters	Holding 10 meters, fixed head 15 meters	Holding 10 meters, fixed head 15 meters
Blowing protection	Argon, nitrogen	Argon, nitrogen	Argon, nitrogen
Electricity demand	Single phase AC220 V / 50 Hz	AC220V/380V/50Hz	Three phase AC380V / 50Hz
Equipment power	3.5Kw	4.5Kw	5.5Kw
area covered	1*1.6m	1*1.6m	1*1.6m
Overall weight	180Kg	200Kg	200Kg
working temperature	0~40℃	0~40℃	0~40℃
Working humidity	10~75%	10~75%	10~75%
Environmental needs	No vibration, no interference source, keep ventilation
Consumables	Purified water, argon	Purified water, argon	Purified water, argon
