fiber laser welding machine price

$8000.00

≥2400 Set/Sets

Min. Order:: 2400 Set/Sets

Min. Order:: 2400 Set/Sets

Transportation:: Ocean, Land, Express

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	L/C,T/T,D/P,D/A,Paypal
Incoterm:	FOB,CFR,CIF,EXW,FAS,FCA,CPT,CIP,DEQ,DDP
Transportation:	Ocean,Land,Express

Product Description

Laser Automation Equipment The automatic fiber laser tube cutting machine integrates the special function module of laser cutting control, which has strong function, good human-computer interface and simple operation.

Based on the windows operating system, the bcut3000s numerical control system and the special platform for laser pipe cutting machine are adopted, and the special function module for laser cutting control is integrated, which has powerful function, good man-machine interface and simple operation.

Laser Automation Equipment Professional pipe cutting programming software is one of the core technologies of CNC pipe cutting machine to achieve "full-time cutting, efficient cutting", which is the fundamental guarantee to effectively save materials and improve cutting efficiency.

The capacitive fiber laser cutting head has the advantages of high induction precision, sensitive response and the most stable and reliable performance.

Laser Automation Equipment The unique trusteeship device keeps contact with the surface of the pipe when the pipe is fed and rotated. The support force is set according to the pipe specification to ensure effective support, prevent the pipe from sagging, reduce the axis swing when the pipe rotates, and improve the processing accuracy.

Automatic whole bundle feeding function (optional), reduce the number of operators and improve the processing efficiency at the same time.

model	UK-HJLX-SC500W	UK-HJLX-SC1000W	UK-HJLX-SC1500W
laser power	500w	1000w	1500w
Laser wavelength	1070±5 nm	1070±5 nm	1070±5 nm
Operation mode	Continuous / modulation	Continuous / modulation	Continuous / modulation
Output welding joint type	Hand held swinging head	Hand held swinging head	Hand held swinging head
Output power stability	＜3%	＜3%	＜3%
Power regulation range	10~100%	10~100%	10~100%
Weld penetration	0.5~2.0mm	0.5~2.0mm	0.5~2.0mm
Spot width	0.2-3mm	0.2-3mm	0.2-3mm
Cooling mode	Built in water cooling	Built in water cooling	Built in water cooling
Fiber line length	Standard 10 meters, Max15 meters	Standard 10 meters, Max15 meters	Standard 10 meters, Max15 meters
Blowing protection	Argon, nitrogen	Argon, nitrogen	Argon, nitrogen
Electricity demand	AC220v/50Hz	AC220v/380v/50Hz	AC380v/50Hz
Equipment power	3.5 Kw	4.5 Kw	5.5 Kw
area covered	1*1.6m	1*1.6m	1*1.6m
Overall weight	180 Kg	200 Kg	200 Kg
working temperature	0~40°C	0~40°C	0~40°C
Working humidity	10~75%	10~75%	10~75%
Environmental requirements	No vibration, no interference source, keep ventilation	No vibration, no interference source, keep ventilation	No vibration, no interference source, keep ventilation
Consumables	Purified water, argon	Purified water, argon	Purified water, argon

Working drawing
