Robot laser welding equipment

Advantages of manipulator laser welding machine:
The optical fiber transmission YAG laser welding machine with fixed and mobile processing functions can be fixed and separated from the host.
It is applicable to the processing of workpieces with complex shapes, reduces the requirements for tooling fixtures, achieves one machine with multiple functions, expands the scope of application, and enhances the adaptability of the equipment.
The laser processing head has the functions of manual focusing and CCD supervisor. The optical fiber can move freely and match with the manipulator, creating conditions for complex processing technology solutions.

Technical parameters of manipulator laser welding machine
laser power 1500W / 2200W / 3300W
Laser Standard raycus laser, optional German IPG laser
Laser wavelength 1080±10nm
manipulator Imported kwasaki (Kawasaki) manipulator is standard, and ABB manipulator can be selected
operation mode continuity
Laser mode Multimode / single mode
Fiber length 20M
Cooling mode water-cooling
Maximum laser power 1500W / 2200W / 3300W
Overall power ＜ 10KW / ＜15KW / ＜20KW
Power regulation range 5-95%
Transmission fiber core diameter 50um or 100um
Minimum spot 0.2mm
Maximum spot 5mm (swing welding)
Welding positioning Red CCD (vision and laser altimetry optional)
Power input AC380V±10%/3P+N+PE
