portable 20w fiber laser marking machine

$10000.00

≥4800 Set/Sets

Min. Order:: 4800 Set/Sets

Min. Order:: 4800 Set/Sets

Transportation:: Ocean, Land, Express

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	L/C,T/T,D/P,D/A,Paypal
Incoterm:	FOB,CFR,CIF,EXW,FAS,FCA,CPT,CIP
Transportation:	Ocean,Land,Express

Product Description

Hand held portable laser marking machine, hand-held laser marking machine is small and convenient, can be used as an ordinary laser marking machine, can also be used to work with a laser head, hand-held laser marking machine can carry out laser marking of large mechanical parts in any direction, to solve the existing problems of laser marking of large parts. Hand held laser marking machine, good beam quality, high efficiency, long life (average life 100000 hours), maintenance free, small size, no consumables, air cooling, low energy consumption, almost no operating cost.
Characteristics of portable laser marking machine
1. It is especially suitable for marking work pieces with large volume or heavy weight which are inconvenient to handle.
2. Integrated modular design, convenient maintenance, small size. Save your valuable workshop space.
3. The all fiber structure design of the laser ensures the high reliability of the laser without any optical element alignment adjustment.
4. Long service life, small size, without huge water cooling system, just simple air cooling can be.
5. In a certain impact, vibration, high temperature or dust and other harsh environment can also work normally.
6. Processing speed is 2-3 times of the traditional laser marking machine, excellent beam quality, small spot, marking line width is very narrow, suitable for fine marking.
7. The utility model has the advantages of low cost, power saving and energy saving, and the power of the whole machine is only 500W. Compared with lamp pump and semiconductor laser marking machine, it can save 20000-30000 yuan of electricity every year.
8. The integrated design of the system makes it more convenient for customers to use, and provides an ideal solution for various industrial applications.

Technical parameters of portable laser marking machine

Modelname	HT-GX20	HT-GX30	HT-GX50	HT-GX100
Laserpower	20W	30W	50W	100W
Laserwavelength	1064nm
Frequency	20-100KHz
Markingarea	110X110mm145X145mm175X175mm (Optional)
Markingdepth	0.01-0.3mm 0.01-0.5mm
Markingspeed	≤7000mm/s
Minilinewidth	0.02mm
Mincharacter	0.2mm
repeatedaccuracy	0.002mm
Coolingsystem	Aircooling
Powersupply	AC220V/50Hz
powerconsumption	800W 1000W
