Automatic laser numerical control cutting machine

For large panel materials for efficient cutting, batch application in construction machinery, shipbuilding, rail transit industry. Based on the market demand of a large number of medium and heavy plate groove, we independently developed a large scale five axis groove cutting equipment on the high-speed and high-precision Siemens system.

Equipment introduction
Youkong high performance large format numerical control laser cutting machine adopts the integral moving structure of laser and beam integration, synchronous drive of bilateral gear rack and flying light path. The optimized German Siemens laser cutting special CNC system is equipped with a large worktable, which strengthens the humanized operation and makes the movement stable and reliable.
Double side driving synchronous rack and pinion driving device
High power Siemens AC servo motor is adopted. Longitudinal and transverse use of rack and pinion drive, the use of single-stage differential gearbox transmission, easy maintenance.
1. Airborne structure of laser
Ensure that the laser cutting head runs to different positions, and still get the same precision laser cutting quality
2. Moving beam
Between the guide rails, a moving double beam is driven by two sides. The beam is equipped with laser, laser electric cabinet, external optical system, waterway gas control system, Z axle box and cutting head
3. Fixed worktable
It is convenient for large plate feeding and small plate processing
4. Cable and gas transmission device
Horizontal and vertical cables and gas pipes are transmitted by tank chain belts
Application industry
Construction machinery, ship, locomotive and other industries
