Cylindrical Photoelectric Sensor ES-D08N1/D08N2
-
$17.00≥1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
Your message must be between 20 to 2000 characters
Contact Now| Payment Type: | L/C,T/T |
|---|
M8 positive directional column type photoelectric sensor ES-D08N1/D08N2
- The most suitable column type photoelectric sensor for buried installations
- Through-beam type with a detective distance of up to 1m
- With vibration-resistant resin filling
-
At present, the main products are: safety light curtain, photoelectric switch series, proximity switch series, optical fiber sensor series, ultrasonic sensor, intelligent sensor, displacement sensor, gas pressure sensor, etc. Look forward to your cooperation!
|
Product Model |
Diffuse Reflection Type |
|
|
ES-D08N□ |
||
|
Sensing Distance |
35mm(White paper 30×30mm) |
|
|
Standard Sensing Object |
- |
|
|
Differential Travel |
20% max of the Sensing Distance |
|
|
Directional Angle |
- |
|
|
Light Source (Luminous Wavelength) |
Infrared Emitting Diode(940nm) |
|
|
Power Supply Voltage |
DC12 to 24V±10% Pulse (P-P)10% max |
|
|
Current Consumption |
30mA max |
|
|
Control Output |
Load power supply voltage DC24V max, Load current 80mA max, Residual voltage 1V max |
|
|
NPN Voltage output type |
||
|
Light-ON/ Dark-ON Varies by type |
||
|
Protective Circuit |
Power reverse connection protection |
|
|
Output short circuit protection |
||
|
Anti-interference function |
||
|
Response Time |
Operate and Reset: all 3ms max |
|
|
Ambient Illumination |
On the surface of the receiver Incandescent light: 3000lx; Sunlight: 10000lx |
|
|
Ambient Temperature |
Operating: -25 to +55℃; Storage: -30 to +70℃(With no icing or condensation) |
|
|
Ambient Humidity |
Operating: 35 to 85%RH; Storage: 35 to 95%RH(With no condensation) |
|
|
Insulating Resistance |
20MΩ min(DC500V) |
|
|
Voltage Withstand |
AC500V 50/60Hz 1min |
|
|
Vibration |
Durable |
10-500Hz 1.5-mm up and down amplitude for 2h each in X, Y, and Z directions |
|
Shock |
Durable |
500m/s² for 3 times each in X, Y, and Z directions |
|
Protective Structure |
IEC-60529 IP66 |
|
|
Connecting Method |
Lead-out type (Standard cable length 2m) |
|
|
Quality |
Bundle state |
Approx: 80g |
|
Material |
Case |
Brass |
|
Perspective Lens |
Acrylic Resin |
|
