What 's the next generation PON network system: Xpon ?

Although EPON and GPON have their own different technologies, they have the same network topology and similar network management structure. They are both oriented to the same optical access network application and are not non-convergence. The next-generation PON network system xPON can support at the same time These two standards, that is, xPON equipment can provide different forms of PON access according to the different needs of users, and solve the problem of incompatibility of the two technologies. At the same time, the xPON system provides a unified network management platform that can manage various business requirements, realize full-service (including ATM, Ethernet, TDM) support capabilities with strict QoS guarantee, and support downstream cable TV transmission through WDM; at the same time, it can automatically identify EPON, GPON Access card is added and withdrawn; it is truly compatible with EPON and GPON networks at the same time.

Product Overview:

Gepon Ont fully comply with IEEE 802.3-2005 and the China Telecom XPON device technical specification (V2.1). It is operative, manageable and maintainable at telecommunication level, and can provide high speed data service for customers. It has a PON uplink port that connects to office end apparatus through optical fiber.

Product Features:

1. HGU ONU product form, supporting bridge and NAT mode;

2. BOB product process;

3. 802.11B /g/n wireless access;

4. 2*3dBi external dual antenna is used wirelessly.

5. USB interface supports configuration saving and recovery;

6. Provide a VOIP interface to connect the ordinary telephone;

7. 12V /1.0A External power supply.

8. Conform to IEEE802.3ah standard

9. Support Ethernet service layer 2 switching and wire-speed forwarding of uplink and downlink services

10. Support frame filtering and suppression

VOIP Features:

1. Single channel option, 105V most battery design

2. Available in either PCM/SPI or ZSI

3. Compact structure, 84-pin 7*7mm QFN components

4. VOIP processor and SOCS adopt the 5th generation line interface

5. The voice path SDK and vp-api-ii software can implement FXS functions

6. Energy saving switch control structure: up to 65vrms open circuit, up to 5REN load

7. Two-layer PCB design, complete bandwidth BOESCHT function

8. Analog telephone adapter (ATAs)

WIFI Features:

1. Technical Norms: IEEE802.11b, IEEE802.11g, IEEE802.11n;

2. Debug Mode: 802.11b: DSSS/BPSK/QPSK/CCK; 802.11g: OFDM/DSSS/BPSK/QPSK/CCK; 802.11n: OFDM/DSSS/BPSK/QPSK/CCK;

3. Speed: 802.11b: compatibility 11,5.5,2,1 Mbps; 802.11g: compatibility 54,48,36,24,18,12,9,6 Mbps; 802.11n: compatibility

130,117,104,78,65,58, 52,39,26,19.5,13,6.5Mbps;

4. Channel: 1~11 (USA, Canada); 1~13 (Europe); 1~14 (Japan);

5. Frequency Domain: 2.4GHz-2.4835GHz.
