XPON 4FE WIFI 2POTS USB ONU

What is HG8245C?

Huawei Echo Life HG8245C ONT 4FE+2POTS+1USB+WiFi is an optical network terminal (ONT), is a high-end home gateway in Huawei FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users. The HG8245C provides two  POTS ports, four Ethernet ports and one WiFi port. Our model XPON WIFI ONU 4FE+WIFI+2POTS+USB,it is similar than Huawei HG8245C,but not for Huawei original brand.It with Huawei chipset and same ports like HG8245C.

Product Overview:

GL-GE8004U-HZF type ONU products fully comply with IEEE 802.3-2005 and the China Telecom XPON device technical specification (V2.1). It is operative, manageable and maintainable at telecommunication level, and can provide high speed data service for customers. It has a PON uplink port that connects to office end apparatus through optical fiber.

Product Interface:

Interface: optical port, voice port, network port 1- network port 4, power socket, power switching.

Indicator Light: WPS, wireless, USB, Telephone, network port 1-4, Optical signal, PON registration, power supply.

• Port Features:

>1 PON ports (1.25G)

>4 10/100M port

>2 voice port

• Physical Features:

>Power supply: 12VDC

>Power consumption: 7W

>Working temperature: 0～55℃
>Storage temperature: -30～60℃
>Relative humidity: 10～90% (non-condensing)

• Product Feature:

1. HGU ONU product form, supporting bridge and NAT mode;

2. BOB product process;

3. 802.11B /g/n wireless access;

4. 2*3dBi external dual antenna is used wirelessly.

5. USB interface supports configuration saving and recovery;

6. Provide a VOIP interface to connect the ordinary telephone;

7. 12V /1.0A External power supply.
