Features of XPON 1GE ONU with WiFi Function:

XPON ONT fully complies with the ITU.984 standard IEEE802.3ah, and has the characteristics of carrier-class operation, management, and easy maintenance. It is a bridging home-side device that realizes ultra-broadband access for home/SOHO users through XPON technology. It has a PON uplink interface to connect with the central office equipment through optical fiber. It has a compact structure and can be placed on the desktop, wall-mounted or placed in the corridor information box.

•Conform to ITU-T G.984 GPON standards and IEEE802.3ah EPON standards

>Support Ethernet service layer 2 switching and wire-speed forwarding of uplink and downlink services

>Support frame filtering and suppression

>Support standard 802.1Q Vlan function, support VLAN conversion

>Support 4094 VLANs (802.1Q)

>Support Dynamic Bandwidth Allocation (DBA) function

>Support QoS, including traffic flow classification, priority marking, queue and dispatch, traffic shaping and traffic control, etc

>Single ONU supports up to 1 LLID.

Port Features:

>1 PON ports (2.5G)

>1 10/100/1000M port

>1 WLAN Port

Physical Features:

>Power supply: 12VDC

>Power consumption: 4W

>Working temperature:0～55℃
>Storage temperature: -30～60℃
>Relative humidity: 10～90% (non-condensing)
