Ftth Modem XPON 1ge 1fe Pots Wifi Ont

RJ11 Port is Telephone Port,usually Voip Port,Voice Port,FXS Port,POTS Port all means Telephone Port.With this function,connected ONU also can have telephone call or Voice Function,it is very convienient and can safe cost during telecommucation network project.

XPON Wifi Onu Overview

The XPON ONU series were designed and produced by our company,XPON ONU Router 1GE+1FE+1POTS+ WiFi(2.4G) is a multi-service XPON terminal product with high reliability,high quality,easy management,flexible upgrade and expansion.It is based on the mature GPON&EPON technology,highly reliable and easy to maintain,with guaranteed QoS.

XPON ONU Features:1.Dual mode;2.Support management;3.Support Auto-negotiation and MDI/MDIX;4.Support the Ethernet interface rate,working mode and flows control;5.Support loopback at UNI;6.Support packet filtering and anti-illegal message attack protection;7.Support performance statistics;8.Support VLAN tagged label processing,traffic classification etc;9.Support DHCP;10.Support IGMP Snooping;11.Support SIP Call protocol;12.WAN supports routing mode or bridge mode or routing/bridge hybrid mode;13.Support for IPv4 and IPv6 dual stacks;14.Support OAM/OMCI and TR069.

Hardware Parameter:1.PON Port:1G/EPON Optical Interface;Single Fiber:1*SC/UPC Fiber;2.Upstream Rate:GPON:1.244Gbps EPON:1.25Gbps;3.Downstream Rate: GPON:2.488Gbps EPON:1.25Gbps;4.Type: BOSA;5.Wavelength:Tx 1310nm,Rx 1490nm;6.Optical Output Power:GPON:+0.5~+5dBm EPON:-1~+4dBm;

7.Sensitivity:GPON:-28dBm EPON:-26dBm;8.Overload:GPON:-8dBm EPON:-3dBm;9.LAN:1*10/100/1000Mbps and 1*10/100Mbps;Full / Half-Duplex,RJ45,Auto-MDI/MDI-X;10.POTS:1 FXS,RJ11;11.Wireless:IEEE802.11b/g/n,300Mbps,2T2R,2 External;12.Power:External DC 12V/1.5A power supply adapter;13.Power Consumption:<9W;14.Size:160*114*29MM;15.Weight:<0.3kg;16.Operating Temperature:0～50℃;17.Storage Temperature:-40～85℃ 18.Operating Humidity:10%～90%;19.Storage Humidity:10%～90% VOIP Function Feature;Onu With Wifi Function WIFI Feature
