The Bluetooth RFID reader is EOL( end of life), our RFID Desktop Reader, UHF RFID Desktop Terminal QY-DR100U and UHF RFID Desktop Terminal QY-DR300U are suitable alternatives.
To fulfill the requirements of the customers for E-wallet, E-commerce applications, this Bluetooth reader supports ISO14443-A or ISO18092 or ISO15693. The Bluetooth reader is characterized by its read/write functions, Bluetooth communications, and battery charging management functions, etc.
Overview
Smart outlook, light and handy, portable;
Bluetooth communicates online devices supporting the standard blue tooth 2.0;
Peripheral press button can choose the active reading card mode, convenient to use.
Specifications of Bluetooth RFID Reader
|
Basic Parameters |
|
|
Model |
Bluetooth Reader & Writer |
|
Dimensions |
80.5mm X 52.5mm X 5.5mm |
|
Keys |
One power button, one trigger button |
|
Battery |
Standard 3.7V/420mAh lithium battery |
|
Operating Temp |
-10℃ to +50℃ |
|
Interface |
USB |
|
Wireless Data |
Bluetooth |
|
Communication |
|
|
Indicators |
Buzz LED indicator: charging indicator light |
|
With low battery, LED light or buzz is active. |
|
|
Protection |
Equipped with over-charge protection, over-discharge protection and short-circuit protection |
|
RFID Parameters |
|
|
Frequency Range |
13.56MHz |
|
Protocols and Chip supported |
Option 1:ISO14443A- MIFARE Classic 1K/4K,Ultralight EV1 |
|
Option 2:ISO18092- NTAG203/213/215/216,and Mifare S50,S70,ultralight |
|
|
Option 3: ISO15693-I code sli, I code sli-l, I code sli-s |
|
|
Support OS |
Option 1: PC (windows 32bit) and Android 2.0/4.0 (Available for each above protocol) |
|
Option 2: IOS (Available for each above protocol) |
|
|
Current Consumption |
<150mA |
|
Read Range |
3-5cm, depend on the installation site and the antenna |
|
Bluetooth Module Parameters |
|
|
Frequency Range |
2.4GHz |
|
Bluetooth |
When main machine searching the bluetooth reader and connecting successfully, then can use virtual serial port to communication |
|
Data Rate |
Utmost 115200dps |
|
Indicators |
Bluetooth work indicator |
