Rulon® LR | Superior Chemical Resistance

Rulon® LR is a maroon colored bearing material best known for its versatile design properties. Rulon LR is compatible with most hardened steel substrates. Mild steel is acceptable; harder running surfaces are better. Rulon® has a practically universal chemical inertness. Of the chemicals encountered in commercial practice, only molten sodium and fluorine, at elevated temperatures and pressures, show any signs of attack.

Among the most popular variations of Rulon, Rulon LR is the “Go-To” material for general purpose bearing applications. Rulon LR has a superior chemical inertness, with a ceramic filler for better dielectric and thermal insulation. Our clients depend on Rulon LR’s durability and dependability for high-pressure gaskets, slide pads, compressor components, and light-to-medium duty structural applications. And sleeve bearings made of Rulon LR can operate up to 10,000 PV, or even higher with intermittent service. Rulon LR gives the best chemical resistance for mild-to-hardened steel shafting and couterfaces.

Properties of Rulon LR: Maximum Load ôP" (psi) MPA: 1,000/6.9 Maximum Speed ôV" (fpm) m/s: 400/2.0 Maximum ôPV" (psi-fpm) (Mpa . m/s): 10,000/0.35 Mating Surface Steel & Stainless Steel: — Rb 35 & higher Environment: — Steam, Wet, Dry, Vacuum A high coefficient of friction and Creep resistance

Key Properties

Excellent for Steam, Wet, Dry & Vacuum Environments

Outstanding Chemical Resistance

Low Friction

Ideal for Harder Mating Surfaces

Maximum Pressure Velocity (continuous)(MPa x m/s): 10,000PV (.35)

Maximum Pressure PSI (Static)(MPa): 1,000 PSI (6.9)

Shaft Hardness Minimum: Rc35

Shaft Material: Steel

Limitations

Subject to Creep, Cold Flow

Tight Tolerance Applications
