7.84 Inch TFT LCD Display

Get Latest Price

Payment Type:: T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

When it comes to choosing what to use for your displays, going with the standard can get you farther ahead than thinking outside the box. TFT LCD display gives you an edge for your advertising needs, television screens, or even phone screens.
A thin-film transistor (TFT) is one of the technologies commonly used for building LCDs. With this technology, your LCD is guaranteed a sharp, clear, and full-color display and high-quality performance.
Size: 7.84
Model: 784001I0
Resolution: 400*1280
Viewing angle: IPS
Color: 16.7
Features: high brightness, full viewing angle, square structure
Application areas: medical equipment, automotive electronics, household appliances, advertising machines, outdoor video

ITEM	Sandard value	Unit
Model Number	784001I0
size	7.84	Inch
LCD Type	Normally black	--
Drive element	TFT active matrix	--
Number of pixels	400*3RGB(H)X1280(V)	Dots
Pixel arrangement	RGB stripe	--
Active area	59.4(H) *190.08(V)	mm
LCM Mechanical Outline Size(WHT)	67.8205.784.6	mm
Viewing direction	ALL O’CLOCK	-
LCM Driver IC	OTA7290B	-
LCM interface	MIPI Interface	-
Lcm pin n count	40
Backlight leds	24	pcs
Backlight current	100*240	ma
Backligh voltage	19.8	v
operating temperature	-20+70	℃
storage temperature	-30+80	℃
Lumens degrees	500-900	Cd/㎡
