5.0 inch Color LCD Display Screens

Get Latest Price

Payment Type:: T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

When an LCD is used to display moving images the inherent slow rate of change between fluid states over a large number of pixel elements can be a problem due in part to capacitive effects, which causes moving image blurring. By putting a high speed LCD controlling device in the form of a thin film transistor right at the pixel element on the glass surface, the LCD image speed issue can be greatly enhanced and for all practical purposes eliminates image blurring.
Other benefits of these thin film transistors are they allow for thinner display designs and different pixel designs and arrangements to vastly improve display viewing angles.

Model: 500062S0
Resolution: 800*480
Viewing angle: IPS
Display color: 16.7M
Product features: wide temperature display, high brightness, full viewing angle, backlit upper and lower stainless steel iron frame design, customizable touch screen
Application areas: security, instrumentation, automotive electronics, industrial control equipment, medical equipment, smart home, Internet of Things, new retail, household appliances, small consumer electronics, etc.

ITEM	Sandard value	Unit
Model Number	500062S0
size	5.0	Inch
LCD Type	Normally black	--
Drive element	TFT active matrix	--
Number of pixels	800*3RGB(H)X480(V)	Dots
Pixel arrangement	RGB stripe	--
Pixel Pitch (W*H)	0.135*0.135	mm
Active area	108(H) * 65.8(V)	mm
LCM Mechanical Outline Size(WHT)	120.775.93.05	mm
Viewing direction	ALL O’CLOCK	-
LCM Driver IC	ST7262A	-
LCM interface	RGB 24 BIT Interface	-
Lcm pin n count	40
Backlight leds	12颗/18颗	pcs
Backlight current	40/60	ma
Backligh voltage	18	v
operating temperature	-30+85	℃
storage temperature	-30+85	℃
Lumens degrees	400/700	Cd/㎡
