3.5 Inch LCD TFT Display

Get Latest Price

Payment Type:: T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

TFT is a Thin Film Transistor, TFT refers to the each LCD liquid crystal display pixels are driven by integration in the behind of the Thin Film Transistor.Therefore, tft-type display has the advantages of high responsiveness, high brightness and high contrast, and its display effect is close to that of CRT display, tft-lcd is one of the most liquid crystal displays.TFT display is also a kind of active matrix liquid crystal display equipment.Tft-lcd is one of the best LCD color display, tft-lcd has the advantages of fine and vivid image, light weight, low power consumption and good environmental protection performance, widely used in TV, laptop, mobile phone, monitor, medical beauty and other equipment.

product manual:
Model: 350075C0
Resolution: 320*480
Viewing angle: IPS
Color: 262K
Structure: LCD+RTP
Features: high brightness, wide viewing angle, back light source upper and lower iron frame design, low power consumption, resistive touch, ESD direct contact: 8KV, air: 15KV
Application areas: automotive electronics, medical equipment, digital electronics, smart home, white goods, etc.

ITEM	Sandard value	Unit
Model Number	350075C0
size	3.5	Inch
LCD Type	Normally White	--
Drive element	TFT active matrix	--
Number of pixels	320*3RGB(H)X480(V)	Dots
Pixel arrangement	RGB stripe	--
Pixel Pitch (W*H)	0.153*0.153	mm
Active area	48.96(H) * 73.44(V)	mm
RTP+LCM Mechanical Outline Size(WHT)	54.5833.4	mm
LCM Mechanical Outline Size(WHT)	54.5832.2	mm
RTP Mechanical Outline Size(WHT)	54.2682.541.2	mm
Viewing direction	12 O’CLOCK	-
LCM Driver IC	ILI9488	-
LCM interface	RGB 18 BIT Interface	-
Lcm pin n count	45
Backlight leds	6	pcs
Backlight current	20	ma
Backligh voltage	18.6	v
operating temperature	-20+70	℃
storage temperature	-30+80	℃
Lumens degrees	350	Cd/㎡
