Product Description

A TFT display is a form of Liquid Crystal Display with thin film transistors for controlling the image formation. The technology works by controlling brightness in red, green and blue sub-pixels through transistors for each pixel on the screen.The liquid-crystal behaviour is similar to that of a TN display, relying on 90-degree twisted stacks acting as a waveguide to control the passage of light through the display. The TFT-LCD is able to switch rapidly between ON and OFF states, allowing response times fast enough to support rapid display-update rates suitable for presenting video content or smooth animation.

Model: 240058S0
Resolution: 240*320
Viewing angle: IPS
Color: 262K
Features: high brightness, full viewing angle, ultra-thin design with integrated backlight, low power consumption, MIPI communication, etc.
Application areas: law enforcement, driving recorder, digital camera, medical equipment, handheld PDA, digital electronics, smart home, white goods

ITEM	Sandard value	Unit
Model Number	TXW240058S0
size	2.4	Inch
LCD Type	Normally White	--
Drive element	TFT active matrix	--
Number of pixels	240*3RGB(H)X320(V)	Dots
Pixel arrangement	RGB stripe	--
Pixel Pitch (W*H)	0.051*0.153	um
Active area	36.72(H) *48.96(V)	mm
LCM Mechanical Outline Size(WHT)	40.44572.15	mm
Viewing direction	ALL O’CLOCK	-
LCM Driver IC	ST9852	-
LCM interface	MIPI 1 Lane Interface	-
Lcm pin n count	20
Backlight leds	4	pcs
Backlight current	80	ma
Backligh voltage	3.2	v
operating temperature	-20+70	℃
storage temperature	-30+80	℃
Lumens degrees	700	Cd/㎡
