Solar Horseshoe roadway safety plastic road stud
- Payment Type:
- T/T, D/P, Paypal, Money Gram, Western Union
- Incoterm:
- FOB, CIF, EXW
- Delivery Time:
- 7 Days
- Transportation:
- Ocean, Land
- Port:
- Shenzhen
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | guangdong |
|---|---|
| Productivity: | 50000 |
| Supply Ability: | stock |
| Payment Type: | T/T,D/P,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CIF,EXW |
| Certificate: | CE/ROHS |
| HS Code: | 8530800000 |
| Transportation: | Ocean,Land |
| Port: | Shenzhen |
Product Description
Product Description
How many types of the Solar Horseshoe roadway safety plastic road stud are there?
There are many classifications of road studs. According to the material, they can be divided into cast aluminum road studs; plastic road studs; ceramic road studs; glass ball road studs; reflective bead road studs (21 beads and 43 beads, which can be combined into cast aluminum and plastic road studs) )
Solar Horseshoe roadway safety plastic road stud
The solar road stud is a clear and eye-catching active flashing luminous sight guidance sign, which is continuously arranged to form a luminous lane contour line, which not only plays an excellent and obvious guiding and warning role, but also adds a beautiful scenery line to it. It is mainly installed on highways, approach road shoulders, roundabouts, and roadsides of safety islands.1. Using high-brightness LED light source, double-sided light emission, uniform light emission, soft light, no glare, and good stability.
2. LED active light-emitting with high-efficiency reflective lattice automatic light-reflecting, the effect is more obvious.
3. Strong warning effect, visible distance can reach more than 500 meters.
4. Exquisite appearance. The main body is made of plastic.
5. Easy to install, safe and practical, with low failure rate.
The parameters of The Solar Horseshoe roadway safety plastic road stud:
1. Product model: WDM-DD09-PC
2. Product size: 107 * 95 * 24MM
3. Lamp bead color: red yellow blue green white
4. Number of lamp beads: 6
5. Red wavelength: 620-625NM
6. Yellow wavelength: 590-595NM
7. Blue wavelength: 470-475NM
8. Green wavelength: 520-525NM
9. White brightness: 18900-22600MCD
10. Protection level: IP68
11. Housing material: cast aluminum
12. Battery voltage: 1.2V
13. Solar panel: 2.5V
14. Working temperature: -40 ℃ ~ 60 ℃
15.Working mode: light control (always flashing / always on)
Performance indicators of The Solar Horseshoe roadway safety plastic road stud:
Compression resistance. The exposed solar panels of solar road studs use PC bulletproof materials to enhance the pressure resistance of the electronic parts, IC control is used to reduce the pressure on the electronic parts to reduce the electronic circuit, and the shell is designed with stiffeners to share part of the pressure.
Sealing performance. Separate design, LED lampshade and internal circuit board adopt isolation design. The strong neutral bonding board material is used to ensure that the solar panel, the LED lampshade and the road stud housing are tightly connected.
brightness. The luminous intensity is high, reaching the 2000 MCD target of the Ministry of Transportation.
stability. The battery adopts nickel-metal hydride batteries to meet the national requirements. The electronic circuit follows the simple and effective design principle, and the welding is firm. The solar panel adopts high hardness and wear-resistant circuit boards. Improve the conversion efficiency of solar panels.
The compatibility of the battery.
Environmental adaptability. Special regional conditions can be adjusted appropriately.
It is a kind of road stud. It is set along the road surface and used at night or in rain and fog to indicate the direction of the road. It is composed of retroreflective materials, shells, solar panels, LEDs, and control devices. It has active and passive reflective properties. The visual inducement facilities of the city are usually used in combination with markings.
The installation process of the Solar Horseshoe roadway safety plastic road stud:
Positioning: Determine the installation location, and the installation place should be flat, dry, clean and seamless.
With glue: Stir the glue evenly and have the same color.
Adhesive: Use a moderate amount of glue to stick the road studs firmly to the ground without spilling too much. Apply glue to the underside of the road sign.
Inspection: Check the installed spikes after two hours.
the depth of the space is greater than the depth of the nail feet, and the diameter of the hole is greater than the diameter of the nail feet.
In addition to The Solar Horseshoe roadway safety plastic road stud, our factory also produces other solar road studs:
Plastic Road Stud
Wired Road Stud
Wired Aluminum Road Stud
Led Plastic Road Stud
Aluminum Solar Road Stud
Reflective Aluminum Road Stud
Reflective Road Stud
Garden Road Stud
