Electronic insulating silicone rubber braid sleeve white
Description
Electronic insulating silicone rubber braid sleeve white - Inner fiberglass outside braided silicone rubber is made in accordance with coated electronic insulating sleeves requirements specified in CAN/CSA C22.2ANS as well as NFPA electrical code chapter 1.4 so that this product performs reliably in high temperature environment. And performance after long-term ageing is tested strictly according to the methods specified in UL 746B or the 0.17th chapter of NFPA electrical code. Electronic insulating silicone rubber braid sleeve white provides reliable insulation and protection for inside wire harness of H&N automobiles shipbuilding electrical machinery home appliance selector-heat installations special lamps and lanterns TV and electronic instruments.
Feature
It feels right soft, good electricity, self-extinguishing, solvent resistant
Breakdown voltage:Over 7000V with 50relative humidity, over 2200Vwith 90relative humidity
Operating temperature:-40°C~200°C
RoHS compliant
Standard color:White, other colors on quest
Technical Data
|
Type |
Breakdown voltage(V) |
Volume resistivity (Ω.cm) |
Temperature resistance |
Flammability |
|
|
Average |
Minim |
||||
|
7.0KV |
7000 |
5000 |
1011 |
-40℃~200℃ |
UL1441 VW-1 |
Structure
Dimensions
|
Internal Diameter (mm) |
Wall thickness (mm)
|
|
|
Size |
Tolerances |
|
|
0.5~2.5 |
+0.20 |
0.40 |
|
3.0~4.5 |
+0.30 |
0.45 |
|
5.0~7.0 |
+0.40 |
0.50 |
|
8.0~10.0 |
+0.50 |
0.65 |
|
>12.0 |
>+0.50 |
0.70 |
Note: Non-standard dimensions and packages also available on your request
