RKJX2 Series Joystick controller

Product Number:RKJX21224001

Number of operation axes 1 axis

Axis Material Resin

The joystick reset mechanism has

Varistor Section Maximum Usage Voltage 5V DC

Angle of motion 23 degree Max in all directions.

Resistance Law B (0B)

Total resistance 5 K

Operating life 2,000,000 cycles

Center Press Department Center press has

Maximum rated 5V DC 1mA

Trip 0.35 (+0.5, -0.25) mm

Operating life 500,000 cycles

Use temperature range -10 to +50 C

Electrical Performance Directional Resolution Continuous

Insulation resistance 100Mmin. 250V DC

Voltage resistant 250V AC for 1 minute

Rated power 0.0125W

Sliding noise 300mV P-P max.

Mechanical Performance Directional Motion 7 (+5, -3) mN< M

Press Motion 6.0 +2.5N

Control lever restores essence + (+) 5 degrees

Operating part strength Push direction 98N min. (Push), 50N min. (Pull)

Durability Operating Life Direction 2,000,000 cycles

Center press 500,000 cycles

Environmental resistance - Cold resistance - 30 C 96h

Heat resistance 80 C 96h

Humidity resistance 60 C, 90 to 95%RH 96h

Minimum Order Unit (pcs.) Japan 1,484

Export 1,484
