3.0 × 2.0mm Small Touch Switch

SKSWCEE010 is a small 3.0×2.0mm type with bumps. It contributes to the thinning of combined parts. A small surface mount switch with a switch height of 0.58mm. This product has an operating force of 1.8N and an operating life of 300,000 cycles. The protection structure is equivalent to IP67. This product is mostly used in personal audio, cameras, health products, mobile phones and peripheral equipment. You can communicate your needs with us, and we will recommend the most suitable products for you according to your needs.

Product Number：SKSWCEE010

Type:Surface mount

Action force:1.8N

Operation direction :Top push

Itineraries:0.13mm

Operating Life(5mA 5V DC):300,000 cycles

Initial contact resistance:500mΩ max.

Series：Equivalent to IP67

Operating temperature range：Sharp feeling type

Maximum rating：50mA 12V DC

Minimum Rating：10μA 1V DC

Electrical properties

Insulation Resistance： 100MΩ min. 100V DC for 1min

Withstand voltage ：100V AC for 1 min

Vibration resistance：10 to 55 to 10Hz / min, full amplitude 1.5mm, 2 hours in X, y, Z 3 directions

Environmental resistance

Cold Resistance：-30±2℃ for 96h

Heat resistance：80±2℃ for 96h

Moisture resistance ：60±2℃, 90 to 95%RH for 96h

Minimum Order Unit(pcs.)

Japan：20,000

Exit：20,000
