High Purity 99.99% PSA Nitrogen Generator

High Purity 99.99% PSA Nitrogen Generator

Nitrogen generator takes the principle of PSA(Pressure swing adsorption) and uses the carbon molecular sieve to be
the adsorbent, under the certain pressure, the N2 can be separated from the air when the purified compressed ai
goes through the adsorption vessels by the compressing and decompressing. Due to the property of the oz it moves
faster than N, in the carbon molecular sieve, so the oxygen molecular has been adsorbed first and the N, has been
collected and finally get the N, air. After then the carbon molecular sieve would be decompressed to release the o
molecular, it is called regeneration. Normally it has two towers, one is for working the other is regeneration. They are
all controlled the PLC and valves, so it can keep running without stopping.

The main products of ROC: SMT Cleaning Machine, PSA oxygen / nitrogen generator, wafer cleaning equipment, PCBA Cleaning Machine, PCB Separator, SMT Spare Parts, Reflow / Wave Soldering Machine, SMT Nozzle, SMT Feeder etc. If there is any need, please contact us.

Technical indicators

Nitrogen capacity: 1- 2000Nm3/h
Nitrogen purity: 95%-99.999%
Nitrogen pressure: 0.5-0.8Mpa( boost for high pressure
Nitrogen dew point: s-40.C(Atmosphere pressure)
Customized pressure, purity and capacity ranges.

Technical characteristics
1.The material source is from the nature, the system only needs compressed air and power, so the cost of power and operation is less
2. Nitrogen purity is easy to adjust, it is only affected by the capacity, purity of normal nitrogen is at the range of 95%-99.99%(can be adjusted), purity of high nitrogen is at the range of 99%-99.999%(can be adjusted)
3. The system is automatic, quick starting and no need to monitor. One button for start and stop, run 10-15 minutes to generate the N2 air
4. The working progress is easy, the configuration is compact, the landing space is less and the environment is well-adapted
5. Snow storm filling can avoid the damage of CMs
6. Digital flow meter has pressure compensation, it is highly precise meter which can monitor the progress, it can test quick flow and accumulate the total capacity
