20BYJ46 Miniature Linear Stepper Motor for Smart Lock

Model	Items	SPEC
20BYJ46	Rated Voltage	5VDC
	Phase	4
	Reduction Ratio	1/85
	Steo Angle	7.5°
	Exciting Method	1-2
	Direct-current Resistance	16Ω±10%(25°C)
	No-load pull-in Frequency	≥800Hz
	No-load pull-out Frequency	≥500Hz
	pull-in Torque	≥80mN.m(5VDC.400Hz)
	Detent Torque	≥50mN.m
	Insulation Resistance	≥50MΩ 500VDC
	Dielectric Strenght	500/600VAC(min)
	Insulation Class	B
	Noise	≤40dB
	Friction Torque	39.2-196mN.m
	Terminal Spec	1.5mm*5P
