Basic Info

Product Description

FM-32-QG47-CF Carbon Brush Motor is a type of Carbon Brush Motor.
Carbon Brush Motor is a rotary electric machine that includes a brush device that converts electrical energy into mechanical energy (electric motor) or converts mechanical energy into electrical energy (generator). Brushed motor is the basis of all motors. It has the characteristics of quick start, timely braking, smooth speed regulation in a wide range, and relatively simple control circuit.

FM-32-QG47-CF Carbon Brush Motor Parameters

MODEL	ITEMS	SPEC
FM-32-QG47-CF	Driving Voltage	24VDC
	No-load Current	25mA
	No-load Speed	5000rpm
	Rated Torque	20N·m
	Load Current	70mA
	Load Speed	4600rpm
	Peak current	587.5mA
	Peak Torque	250N·m
	Output Power	0.94W
	Diameter	35.4mm
	Length	26.2mm

Drawing of FM-32-QG47-CF Carbon Brush Motor

FM-32-QG47-CF

Applications of Carbon Brush Motor
• Electric toothbrush
• Electric toys
• Electric tools
• Electric callus removers
• Robot vacuum cleaner
• Automobile electric components
• Small home appliances
• Treadmill
• Medical - Powered surgical instruments, Dental hand tools, Infusion, Volumetric & Insulin Pumps, Diagnostic & scanning equipment
• Security & Access - Security cameras, Locks, Bar code readers, Paging systems
• Aerospace & Defense - Cockpit gauge, Indicators, Satellites, Optical scanners
• Robotics & Factory Automation - Conveyors, Remote controlled vehicles, Industrial robots
• Power Hand Tools - Shears, Pruning hand tools, Nail guns
• Office equipment
• Semiconductors
• Model railways
• Document handling equipment
• Optics equipment
• Automotive
• Transportation equipment
• Audio & video equipment
• Medical Analyzers
• Infusion Pumps
• Electronic Assembly Surface Mount Equipment - Electronic assembly, Robotics and Automated machinery equipment and Pick and place machinery

DC motor stepping motor DC motor

All characteristics above are customizable, if you want Worm Gear Motor, Stepper Motor, Brushless DC Motor, Brush Motor and other motors' OEM / ODM service, please contact us for further information.
