TM043YDHG41-00 4.3 Inch Tianma TFT-LCD
-
$25.001-99 Piece/Pieces
-
$20.00≥100 Piece/Pieces
- Transportation:
- Land, Air, Express, Ocean
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 10000 pcs |
| Supply Ability: | 10000 pcs |
| Payment Type: | Paypal,T/T |
| Incoterm: | FOB,EXW |
| Certificate: | CE, ROHS |
| Transportation: | Land,Air,Express,Ocean |
| Port: | Shenzhen |
This Tianma TFT-LCD is a 4.3 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen.TM043YDHG41-00 supports display 480(RGB)×800 (WVGA) with aspect ratio of 3:5 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 56.16(W)×93.6(H) mm, outline size of 62(W)×112(H)×7.45(D) mm, viewing area size of 57.16(W)×94.6(H) mm, with surface treament of Hard coating, net weight of TBD. As a SFT, Normally Black, Transmissive LCM product, TM043YDHG41-00 can provides 400 cd/m² display brightness 800:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 30 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 63% (NTSC). This product adopted 10S1P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 50K hours, external backlight driver is additionally needed. TM043YDHG41-00 utilizes Parallel RGB (1 ch, 8-bit) + SPI as it's signal inputting systerm, which connected by 45 pins FPC with power supply voltage of 2.8/2.8V (Typ.)(IOVCC/VCC). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
Model P/N
TM043YDHG41-00
Brand
TIANMA
Diagonal Size
4.3"
Panel Type
a-Si TFT-LCD, LCM
Resolution
480(RGB)×800, WVGA 217PPI
Pixel Format
RGB Vertical Stripe
Active Area
56.16(W)×93.6(H) mm
Bezel Opening
57.16(W)×94.6(H) mm
Outline Dim.
62(H)×112(V) ×7.45(D) mm
Treatment
Hard coating
Luminance
400 cd/m² (Typ.)
Contrast Ratio
800:1 (Typ.) (TM)
View Direction
Symmetry
Response Time
30 (Typ.)(Tr+Td)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Operating Mode
SFT, Normally Black, Transmissive
Support Color
16.7M 63% NTSC
Light Source
WLED [10S1P] , 50K hours , W/O Driver
Weight
TBD
Frame Rate
60Hz
Touch Panel
Without
Interface Type
Parallel RGB (1 ch, 8-bit) + SPI , 45 pins FPC
Power Supply
2.8/2.8V (Typ.)(IOVCC/VCC)
Environment
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
Product Picture:
