TM035KVHG01-40 3.5 inch Tianma TFT-LCD
-
$25.001-99 Piece/Pieces
-
$20.00≥100 Piece/Pieces
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 10000 pcs |
| Supply Ability: | 10000 pcs |
| Payment Type: | T/T,Paypal |
| Incoterm: | EXW,FOB |
| Certificate: | CE, ROHS |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shenzhen |
TM035KVHG01-40 is a 3.5 inch diagonal a-Si TFT-LCD display screen product from TIANMA, with a built-in WLED backlight, without backlight driver, touchscreen PCAP. This Tianma TFT-LCD is a 3.5 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. TM035KVHG01-40 supports display 320(RGB)×240 (QVGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 70.08(W)×52.56(H) mm, outline size of 79.9(W)×68.9(H)×4.88(D) mm, net weight of 45g. As a TN, Normally White, Transmissive LCM product, TM035KVHG01-40 can provides 400 cd/m² display brightness 500:1 transimissive contrast ratio, 70/70/60/70 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 12 o'clock , and response time of 20 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 60% (NTSC). This product adopted 6S1P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 20K hours, external backlight driver is additionally needed. TM035KVHG01-40 utilizes Parallel RGB (1 ch, 8-bit) + SPI as it's signal inputting systerm, which connected by 54 pins FPC with power supply voltage of 3.3/3.3V (Typ.)(VDD/VDDIO). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model P/N |
TM035KVHG01-40 |
|
Brand |
TIANMA |
|
Diagonal Size |
3.5" |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
320(RGB)×240, QVGA 115PPI |
|
Pixel Format |
RGB Vertical Stripe |
|
Active Area |
70.08(W)×52.56(H) mm |
|
Outline Size |
79.9(W)×68.9(H) ×4.88(D) mm |
|
Brightness |
400 cd/m² (Typ.) |
|
Contrast Ratio |
500:1 (Typ.) (TM) |
|
Viewing Angle |
70/70/60/70 (Typ.)(CR≥10) |
|
Display Mode |
TN, Normally White, Transmissive |
|
Best View on |
12 o'clock |
|
Response Time |
20 (Typ.)(Tr+Td) |
|
Display Colors |
16.7M 60% NTSC |
|
Lamp Type |
6S1P WLED , 20K hours , Without Driver |
|
Frequency |
60Hz |
|
Touch Screen |
PCAP, I²C |
|
Panel Weight |
45g |
|
Signal Interface |
Parallel RGB (1 ch, 8-bit) + SPI , 54 pins FPC |
|
Input Voltage |
3.3/3.3V (Typ.)(VDD/VDDIO) |
|
Environment |
Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
Product Picture:
