A035QN05 V4 3.5 inch AUO TFT-LCD

$20.00

≥1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Transportation:: Ocean, Land, Air, Express

Port:: HK, Shenzhen

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	TAIWAN
Payment Type:	T/T,Paypal
Incoterm:	FOB,EXW
Certificate:	CE,ROHS,ISO9001
Transportation:	Ocean,Land,Air,Express
Port:	HK,Shenzhen

Product Description

AU Optronics Corp. (hereafter called AUO) A035QN05 V4 (Alias: A035QN05 V.4) is a 3.5 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, without backlight driver, without touch screen. This AUO TFT-LCD is a 3.5 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. A035QN05 V4 supports display 320(RGB)×240 (QVGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 70.32(W)×52.74(H) mm, outline size of 76.9(W)×63.9(H)×2.55(D) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 18.5±2.0g. As a TN, Normally White, Transmissive LCM product, A035QN05 V4 can provides 500 cd/m² display brightness 300:1 transimissive contrast ratio, 60/60/50/55 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 10/15 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 45% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 20K hours, external backlight driver is additionally needed. A035QN05 V4 utilizes Serial RGB (8-bit) + SPI as it's signal inputting systerm, which connected by 50 pins FPC with power supply voltage of 3.3/3.3V (Typ.)(VDD/VDDIO). It's typical vertical frame rate (Fv) is 60Hz.

We are able to offer AD board for this display to support VGA video input.

Model	A035QN05 V4
Brand	AUO
Diagonal Size	3.5 inch
Type	a-Si TFT-LCD, LCM
Pixel Format	320(RGB)×240 [QVGA] 115PPI
Configuration	RGB Vertical Stripe
Active Area	70.32(H)×52.74(V) mm
Outline Dim.	76.9(H)×63.9(V) ×2.55(D) mm
Treatment	Antiglare, Hard coating (3H)
Luminance	500 cd/m² (Typ.)
Contrast Ratio	300:1 (Typ.) (TM)
View Direction	6 o'clock
Response Time	10/15 (Typ.)(Tr/Td)
Viewing Angle	60/60/50/55 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Support Color	16.7M 45% NTSC
Light Source	WLED , 20K hours , W/O Driver
Weight	18.5±2.0g
Frame Rate	60Hz
Touch Panel	Without
Interface Type	Serial RGB (8-bit) + SPI , 50 pins FPC
Power Supply	3.3/3.3V (Typ.)(VDD/VDDIO)
Environment	Operating Temperature: -10 ~ 70 °C ; Storage Temperature: -40 ~ 80 °C
