50Kg Load Remote Control Metal Track Chassis
- Min. Order:
- 1 Others
- Min. Order:
- 1 Others
- Transportation:
- Ocean, Air
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 100/Month |
| Supply Ability: | 100/month |
| Payment Type: | T/T,Paypal |
| Incoterm: | EXW |
| Certificate: | * |
| HS Code: | 8424899990 |
| Transportation: | Ocean,Air |
| Port: | Shenzhen |
Agricultural Spraying Unmanned Vehicle Designed for the fruit farm pets control.It It support route plan auto spraying (optional) ,50L pesiticide tank and 2 of air compression nozzles for perfect atomiztion. max payload upto 150kg. Intergrated camera and video transimtter.
50kg load rubber vehicle rubber track system robot tracks platform crawler rubber track platform robot car chasis sprayer car .
Package included :
Small robot rubber track platform only* 1set
(Note : this price don't include the remote controller ,if you need controller ,should add additional fees for controller. Thank you )
Specifications:
| Product Name | 50KG Load Small robot rubber track |
| speed | 0~2m/s |
| rated power | 350w*2 |
| rated voltage | 22~26V |
| rated current | 25A |
| caterpillar width | 80mm Rubber mixed Kevlar fiber caterpillar |
| maximum gradeability | 40° |
| rated payload | 50 KG |
| N.W. | 23 KG |
| measurment | 650*480*190 |
| battery tank cap | 230*200*110 (maximum 3* 6S 22000mah) |
| endurance time(with load) | 50 minutes 6S 22000mah, 100 minutes 6S 44000mah |
| body materials | T1.5 stainless steel (W/black paint) |
| Color | Black |
Small robot rubber track is a universal crawler robot chassis with independent Christie suspension, which can help to rduce vibration at the time of heavy load. Its interior is equipped with high torque brushless DC gear motor, making the chassis strong and powerful to surmount any obstacles along its way.
The accurate height of chassis, combined with motor of appropriate power, which gives it many advantages including low vravitational center, outstanding obstacle-surmounting properties, vibration reduction for heavy load and stable operation. That’s why it can be appled to many complex robot movement solutions.
Use your imagination. It can do whatever you want........
Application :
1). Exploration of inspection
2). The rescue vehicle
3). Scientific research and education
4). Fire control security guard
5). Special photography
6). Special transport
